TECHNICAL DATA
7-2
©
200416
XE engine inlet/exhaust system
0
ΧΦ65/75/85 series
4
Explanation of GARRETT turbocharger type
designation
Example of type designation: GT40-88S/54NPS/
0.95-84
Turbocharger
GARRETT wastegate
K.K.K. wastegate
Exhaust back pressure
Inlet underpressure
GT40 Turbine type designation
88 Maximum compressor rotor diameter
S Wastegate model
54 Compressor rotor trim
NPS Version with intake side without compressor housing bypass
PS Version with intake side with compressor housing bypass
0.95 Turbine housing size
84 Turbine rotor trim
Stud bolts for fastening Copaslip
Movement of control rod at 1.60 ≥ 0.05 bar 1.0 mm
Movement of control rod at 1.95 ≥ 0.05 bar 3.5 ≥ 0.05 mm
At full-load engine speed 90 mbar
At full-load engine speed (clean air filter) 50 mbar
At full-load engine speed (clogged air filter) 75 mbar
