200324 4-1
Removal and installation
ENGINE BRAKE, PE ENGINE
CF65/75/85 series
4
7
4. REMOVAL AND INSTALLATION
4.1 REMOVAL AND INSTALLATION OF EXHAUST BRAKE
Removing the exhaust brake
1. Disconnect the air supply connection from
the operating cylinder.
2. Remove the heat shield from the exhaust
elbow.
3. Remove the 6 attachment nuts holding the
exhaust elbow to the turbocharger.
4. Remove the clamping strip with which the
exhaust elbow is attached to the exhaust.
5. Remove the exhaust elbow including the
butterfly valve.
Installation, exhaust brake
1. Check the butterfly valve for smooth
operation.
2. Check the sealing faces of the exhaust
elbow and the exhaust pipe.
3. Clean the turbocharger stud bolts and apply
heat-resistant grease to the threads.
4. Fit the exhaust elbow and butterfly valve.
5. Evenly tighten the attachment nuts to the
specified torque.
6. Fit the clamping strip.
7. Check the setting of the exhaust brake; see
"Inspection and adjustment".
