CE ENGINE FUEL SYSTEM
2-4
©
200416
General
2
ΧΦ65/75/85 series
4
1. Suction pipe to electronic unit cooling plate
2. Fuel rail pressure sensor
3. Fuel pipe to fuel rail
4. Fuel rail
5. Fuel return overflow valve
6. Fuel rail pressure-limiting valve
7. Return pipe from fuel return overflow valve
8. Fuel pipe to high-pressure pump
9. Fuel pipe to fuel fine filter
10. High-pressure pump leak-off pipe
11. Fuel pipe to fuel lift pump
12. High-pressure pump
13. Fuel pump control solenoid valve
14. Fuel pipe to high-pressure pump
15. Return pipe to fuel tank
16. Fuel temperature sensor
17. Fuel fine filter
18. Fuel pipe from electronic unit cooling plate
19. ECS-DC3 electronic unit
