CE ENGINE FUEL SYSTEM
2-6
©
200416
General
2
ΧΦ65/75/85 series
4
1. Suction pipe to electronic unit cooling plate
2. Fuel rail pressure sensor
3. Fuel pipe to fuel rail
4. Fuel rail
5. Fuel return overflow valve
6. Fuel rail pressure-limiting valve
7. Return pipe from fuel return overflow valve
8. Fuel pipe to fuel fine filter
9. High-pressure pump leak-off pipe
10. Fuel pipe to fuel lift pump
11. High-pressure pump
12. Return pipe to fuel tank
13. Fuel pump control solenoid valve
14. Fuel pipe to high-pressure pump
15. Fuel supply pipe
16. Fuel fine filter
17. Fuel pipe from electronic unit cooling plate
18. ECS-DC3 electronic unit
