Switch Configuration 65
when the event is triggered, the
system will log
Set the table creator, ownername
for 1 ~ 30 characters of a string
【Instruction】
At the time of configuration Rmon Snmp functions must be open; otherwise the prompt dialog
box will appear.
【Configuration Example】
Such as: create an event to trigger 345, the system sends the trap message and log.
Configuration example Figure 4-129
4.10.3.4 Alarm group
In the navigation bar to select" Snmp>Rmon config>alarm group", define alarm group. The
following picture.
Alarm group Figure 4-130
【Parameter Description】
The alarm list items index
number, value range is 1 ~ 65535
Statistical type
values :3:DropEvents. 4:Octets.
5:Pkts. 6:BroadcastPkts.
7:MulticastPkts.
8:CRCAlignErrors.
9:UndersizePkts.
10:OversizePkts. 11:Fragments.
12:Jabbers. 12:Collisions.
14:Pkts64Octets.
