Dahua 5000 Series User Manual

System Configurations 35
 This part also applies to TV wall device.
Enter IP address of matrix at address bar of the browser, and then press Enter. Step 1
Matrix login interface is displayed. See Figure 4-23.
Matrix login interface Figure 4-23
Enter username and password. Step 2
Click Login to enter web interface. Step 3
4.3.1.1 Adding Network Signal
Search or add network signals manually.
Select Setup > Signal Management > Network Signal. Step 1
The Network Signal interface is displayed. See Figure 4-24.
Registration Figure 4-24
Add network signals. Step 2
 Click Device Search to show search results, select the needed device and then
click Add.
 Click Add to set parameters in the pop-up dialog box.

Dahua 5000 Series Specifications

General

Brand	Dahua
Model	5000 Series
Category	Keyboard
Language	English
