Local Configurations 87
Indicates the main screen port.
Select the Time Display check box, the current system time
displays in each channel window in live view screen. To hide
the time, clear the check box.
Select the Channel Title check box, the channel name,
channel number and recording status display in each channel
window in live view screen. To hide the time, clear the check
box.
Select the Original Rate check box, the video image displays
in its actual size in the channel window.
Select the IVS Rule Preview check box to enable IVS rule
preview function.
Select the SMD Preview check box to enable SMD preview
function.
Maximum three SMD boxes can be displayed at the same
time.
Select the Live Audio check box to enable the audio
adjustment function in the channel window on the live view
screen.
Move the slider to adjust the volume of live audio.
Configure the transparency of the graphical user interface
(GUI). The higher the value, the more transparent the GUI
becomes.
Select resolution for the video. The default resolution for VGA
port and HDMI port is 1280×1024.
Some of the resolution options might not be supported on the
HDMI port.
General: No information is displayed on the channel
window.
Show Face List: Displays the detected face snapshots
taken as a result of face detection on the bottom of the
live view screen.
Not all models support this function.
Enable extra screen function. After this function is enabled,
you can select which port as extra screen port, and the other
port automatically becomes the main screen port.
Select the VGA port or HDMI port as the port connected by a
secondary monitor. For example, if you select HDMI port as
the extra screen port, the VGA port automatically becomes
the main screen port. A device that supports HDMI2 can only
select HDMI2.
Select resolution for the video. The default resolution for VGA
