Local Configurations 113
Figure 5-72
Configure the settings for the text overlay parameters. See Table 5-26. Step 2
In the Channel list, select the channel that you want to configure the
settings for.
Select the Time Display check box to display the system time on
each channel window in the live view screen.
In the Time Display list, select time display style.
Select the Channel Title check box to display the channel name on
each channel window in the live view screen.
In the Channel Title box, enter the name for the selected channel.
Table 5-26
Click Apply to complete the settings. Step 3
Click Copy to copy the settings to other channels.
5.5.4 Configuring Covered Area Settings
Select Main Menu > CAMERA > OVERLAY > Cover-Area. Step 1
The Cover-Area interface is displayed. See Figure 5-73.
