Dahua DH-XVR4108C-X User Manual

Local Configurations 282
Figure 5-256
Configure the settings for the FTP settings parameters. See Table 5-75. Step 2
Parameter
Description
Enable
Enable the FTP upload function.
FTP type
Select FTP type.
FTP: Plaintext transmission.

SFTP: Encrypted transmission (recommended)

Server
IP address of FTP server.
Port
FTP: The default is 21.

SFTP: The default is 22.

Anonymity
Enter the user name and password to login the FTP server.
Enable the anonymity function, and then you can login
anonymously without entering the user name and password.
User Name
Password
Remote Directory
Create folder on FTP server.
If you do not enter the name of remote directory, system

automatically creates the folders according to the IP and
time.
If you enter the name of remote directory, the system creates

the folder with the entered name under the FTP root
directory first, and then automatically creates the folders
according to the IP and time.

Dahua DH-XVR4108C-X Specifications

General

Main Processor	Embedded Processor
Operating System	Embedded LINUX
Video Input	8 channels
Two-way Talk	Reuse audio in/out, RCA
Record Interval	1~60 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec
Video Output	1 HDMI, 1 VGA
OSD	Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Max. User Access	128 users
Smart Phone	iPhone, iPad, Android
Internal HDD	1 SATA Port, up to 6TB capacity
Power Supply	DC12V/2A
Power Consumption	<10W (without HDD)
HDCVI Camera	Supported
AHD Camera	Supported
TVI Camera	Supported
Audio In/Out	1 channel in/1 channel out
Recording Resolution	1080p; 720p; 960H; D1; CIF
Record Mode	Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection), Alarm
Resolution	1920×1080; 1280×1024; 1280×720; 1024×768
Multi-screen Display	1/4/8/9
Compression	H.264
Ethernet	1x RJ-45
Network Functions	HTTP, HTTPS, TCP/IP, IPv4, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, Alarm Server, P2P, IP Search (Support Dahua IP camera, DVR, NVS, etc.)
USB Interface	2 USB 2.0
Operating Conditions	-10°C ~ +55°C / 10%~90%RH
