Dahua NVR2104HS-P-S3 - Front Panel and Rear Panel; Front Panel; Nvr41-4 Ks2;Nvr41-P-4 Ks2;Nvr41-8 P-4 Ks2;Nvr41-4 Ks2;L;Nvr41-P-4 Ks2;L; NVR21-8 P-S3;NVR41-EI;NVR41-P-EI;NVR41-8 P-EI Series

2 Front Panel and Rear Panel
The following front panel and rear panel gures are for reference only.
2.1 Front Panel
2.1.1 NVR41-4KS2/NVR41-P-4KS2/NVR41-8P-4KS2/
NVR41-4KS2/L/NVR41-P-4KS2/L/NVR41-8P-4KS2/L/
NVR21-4KS2/NVR21-P-4KS2/NVR21-8P-4KS2/NVR21-S3/
NVR21-P-S3/NVR21-8P-S3/NVR41-EI/NVR41-P-EI/NVR41-8P-
EI Series
The gure is for reference only.
The NVR41-4KS2/NVR41-4KS2/L/NVR41-P-4KS2/NVR41-P-4KS2/L/NVR21-4KS2/NVR21-P-4KS2/
NVR21-S3/NVR21-P-S3/NVR41-EI/NVR41-P-EI front panel is shown as below.
Figure 2-1 Front panel
The NVR41-8P-4KS2/NVR41-8P-4KS2/L/NVR21-8P-4KS2/NVR21-8P-S3/NVR41-8P-EI front panel is
shown as below.
