Port Name Connection Function
Network port
10/100/1000 Mbps self-adaptive Ethernet port.
Connect to the network cable.
●
NVR41-EI series supports 10/100 Mbps or
10/100/1000 Mbps.
●
NVR41-P-EI series supports 10/100 Mbps.
●
NVR41-8P-EI series supports 10/100/1000 Mbps.
The parameters might be dierent according to
the models. Please refer to actual device for
detailed information.
USB port
USB port. Connect to mouse, USB storage device
and more.
HDMI
High Denition Media
Page
High denition audio and video signal output port.
It transmits uncompressed high denition video
and multiple-channel data to the HDMI port of the
display device. HDMI version is 1.4.
VGA VGA video output port
VGA video output port. Output analog video
signal. It can connect to the monitor to view
analog video.
MIC IN Audio input port
Bidirectional talk input port. It is to receive the
analog audio signal output from the devices such
as microphone, pickup.
MIC OUT Audio output port
Audio output port. It is to output the analog audio
signal to the devices such as the sound box.
●
Bidirectional talk output.
●
Audio output on 1-window video monitor.
●
Audio output on 1-window video playback.
GND Ground end.
PoE PORTS PoE port
Built-in switch. Support PoE function.
For PoE series product, you can use this port to
provide power to the network camera.
