2.1.11 NVR48-4KS2/I/NVR48-16P-4KS2/I/NVR54-EI/
NVR54-16P-EI/NVR58-EI/NVR58-16P-EI/NVR48-EI/
NVR48-16P-EI
The gures are for reference only.
The NVR48-4KS2/I/NVR48-16P-4KS2/I series front panel is shown as below.
Figure 2-20 Front panel
The NVR54-EI / NVR54-16P-EI front panel is shown as below.
Figure 2-21 Front panel
The NVR58-EI/NVR58-16P-EI/NVR48-EI/NVR48-16P-EI front panel is shown as below.
Figure 2-22 Front panel
Table 2-10 Icons
Icon
Name Function
HDD HDD status indicator light
The blue light is on when the HDD
malfunctions.
NET Network status indicator light
The blue light is on when the
network connection is abnormal.
User's Manual
14
