2.1.15 NVR624-XI Series
The following gures are for reference only.
The front panel of NVR624-XI series is shown as follows.
Figure 2-28 Front panel
Table 2-15 Icons
No.
Name Function
1 Front panel lock —
2 USB port —
3 Network indicator light
The blue network indicator light is on after you
connected the device to the network.
4 Alarm indicator light
The alarm indicator light becomes on once an alarm
occurred. It becomes on via the software detection.
The indicator light becomes on when there is a local
alarm.
5
System HDD indicator
light
The blue light becomes on after system booted up
properly.
In the system HDD, there are device important
conguration le, factory default conguration le,
and device initial boot up data.
User's Manual
19
