Dahua NVR2104HS-P-S3 User Manual

No. Name No. Name
7 VGA Port 8 AUDIO IN, RCA Connector
9 AUDIO OUT, RCA Connector 10 RS-232 Port
2.2.30 NVR11HS-W-S2-CE/NVR11HS-W-S2-FCC Series
Figure 2-96 Rear panel
Table 2-45 Ports
Icon
Name Function
USB 2.0 port
USB 2.0 port. Connect to mouse, USB storage
device, USB burner and more.
Network port
10/100 Mbps self-adaptive Ethernet port.
Connect to the network cable.
HDMI High Denition Media Page
High denition audio and video signal output
port. It transmits uncompressed high
denition video and multiple-channel data to
the HDMI port of the display device. HDMI
version is 1.4.
User's Manual
69
