Local Basic Operations 115
This area includes Mark List and File List.
Different series products have different functions. The icons
displayed may vary. The actual product shall prevail.
: Click the Mark List button, the marked recorded video
list is displayed. Double-click the file to start playing.
: Click the File List button, the searched recorded video
list is displayed. You can lock/unlock the files. Refer to
"4.6.7 File List " for detailed information.
Fisheye dewarp. It is to display the dewarp fisheye
video. Refer to "4.3.5.2 Fish eye de-warp during playback" for
detailed information.
You can select 24hr, 2hr, 1hr, or 30min as the unit of time bar. The
time bar display changes with the setting.
All the operations here (such as playback speed, channel, time and progress) have relationship
with hardware version. Some series NVRs do not support some functions or playback speeds.
4.6.2.1 Playback Control
The playback control interface is shown as below. See Figure 4-93.
Figure 4-93
Refer to the following sheet for more information. See Table 4-24.
Table 4-24
Play/Pause
In slow play mode, click it to switch between play/pause.
Stop
When playing back, click to stop current playback process.
Backward play
In normal play mode, left click the button, the file begins backward
play. Click it again to pause current play.
In backward play mode, click or to restore normal play.
