Local Basic Operations 174
Select the check box, the NVR device records the alarm information in the log
when an alarm occurs.
Check the box and then select the corresponding audio file from the dropdown
list. System plays the audio file when the alarm occurs.
Refer to 4.17.1 File Manage to add audio file first.
Select the check box to activate the buzzer when an alarm occurs.
Step 3 Click Apply to complete the setup.
4.7.2.7 People Counting
System adopts video image and graphics analysis technology. System can calculate the
entry/exit people amount in the specified zone on the video. It can generate an alarm when the
amount has exceeded the threshold.
4.7.2.7.1 People Counting
Step 1 Select Main Menu > AI > PARAMETERS > PEOPLE COUNTING > PEOPLE
COUNTING.
The PEOPLE COUNTING interface is displayed. See Figure 4-154.
Figure 4-154
Step 2 Configure parameters. See Table 4-40.
