Daiichi Electronics SQLC-110L - Detailed Setting Explanations; Setting Mode 1 Details

SQLC-214-097
45
Items Setting and operation procedures Page
Set the leakage
detected circuit
configuration.
(by 3-phase 3-wire)
(163)
Press
SET for longer than 3 seconds Press MODE Press MODE Press MODE
(111) (121AL) (131H) (141H)
Press
MODE Press MODE Press RESET/SHIFT Press RESET/SHIFT
(151H) (161) (162) (163)
Select a circuit by ＋ and －
Press SET Selected circuit is entered
Press
DISPLAY Returns to display mode.
56
Set the ZCT used
by current-leakage
measurement.
(164)
Press
SET for longer than 3 seconds Press MODE Press MODE Press MODE
(111) (121AL) (131H) (141H)
Press
MODE Press MODE Press RESET/SHIFT Press RESET/SHIFT
(151H) (161) (162) (163)
Press
RESET/SHIFT Select a ZCT type by ＋ and － Press SET
(164)
Selected ZCT type is entered
Press DISPLAY Returns to display mode.
56
(14) Backlight setting
Each parenthesized number shows a setting number and this number is displayed on the setting screen.
Items Setting and operation procedures Page
Set the action of
backlight.
(171)
Press
SET for longer than 3 seconds Press MODE Press MODE Press MODE
(111) (121AL) (131H) (141H)
Press
MODE Press MODE Press MODE Select a backlight action by ＋ and －
(151H) (161) (171)
Press
SET Selected backlight action is entered Press DISPLAY Returns to
display mode.
57
Set the brightness
of backlight.
(172)
Press
SET for longer than 3 seconds Press MODE Press MODE Press MODE
(111) (121AL) (131H) (141H)
Press
MODE Press MODE Press MODE Press RESET/SHIFT
(151H) (161) (171) (172)
Select a brightness by ＋ and －
Press SET
Selected backlight brightness is entered
Press DISPLAY Returns to display mode.
57
(15) Other, measurement setting
Each parenthesized number shows a setting number and this number is displayed on the setting screen.
Items Setting and operation procedures Page
Set the dead band
of measurement
display.
(321)
Press
SET and DISPLAY together for longer than 3 seconds Press MODE
(311) (321)
Select of dead band value in measurement display by ＋ and －
Press SET
The value of dead band in display is entered
Press DISPLAY Returns to display mode.
67
Set the tidal
current measurement
of reactive power
and power-factor.
(322)
Press
SET and DISPLAY together for longer than 3 seconds Press MODE
(311) (321)
Press
RESET/SHIFT Select a tidal current measurement ON/OFF by ＋ and －
(322)
Press
SET Selected action is entered Press DISPLAY Returns to display mode.
67
