SQLC-214-097
59
◆ 211 Voltage range
Set the voltage range (VT ratio). Change of this setting also sets the measurement range of active power and reactive
power automatically simultaneously.
Selection by
＋ and － , set value is updated by SET .
Default setting：6600V(3φ3W)、110.0V(1φ3W)、3300V(1φ2W)
Voltage measurement range (34 range)
◆ 212 Current range
Set the current range (CT ratio). Change of this setting also sets the measurement range of active power and
reactive power automatically simultaneously.
Selection by
＋ and － , set value is updated by SET .
Default setting：100.0A(3φ3W)、500A(1φ3W)、50.0A(1φ2W)
Current-measurement range (76 range)
◆ 213 Current display intrinsic sensitivity
Set the full scale of current meter.
The setting range is 40 to 120％ of CT ratio. And, it can select from the following values.
Selection by
＋ and － , set value is updated by SET .
Default setting：100.0A(3φ3W), 500A(1φ3W), 50.0A(1φ2W)
The measurement range (current, active
power, reactive power) which can be set.
(×10
n
)
Example )
In case of CT ratio＝100.0A.
･40％ of 100A is 40A.
･120％ of 100A is 120A.
A measurement range can be
selected within the limits
of 40 to 120A.
Therefore, a left table
A measurement range can be
selected from
40/42/45/48/50/56/60/64/72/
75/80/84/90/96/100/120A.
1.□ 1.0／1.2／1.4／1.5／1.6／1.8
2.□ 2.0／2.4／2.5／2.8
3.□ 3.0／3.2／3.6
4.□ 4.0／4.2／4.5／4.8
5.□ 5.0／5.6
6.□ 6.0／6.4
7.□ 7.2／7.5
8.□ 8.0／8.4
9.□ 9.0／9.6
Voltage range
Setting factor
Setting No.
New setting
Current setting
Current display intrinsic
sensitivity
Setting factor
Setting No.
New setting
Current setting
150.0V(110V)
150V (110V)
300.0V(220V)
300V (220V)
500V (380V)
600V (440V)
600V (460V)
600V (480V)
1200V (880V)
1500V (1100V)
2400V (1650V)
3000V (2200V)
3.00kV (2200V)
150.0kV (110kV)
180.0kV (132kV)
210.0kV (154kV)
270.0kV (187kV)
300.0kV (220kV)
400.0kV (275kV)
500.0kV (380kV)
750.0kV (550kV)
4500V (3300V)
4.50kV (3300V)
9000V (6600V)
9.00kV (6600V)
15.00kV (11kV)
18.00kV (13.2kV)
18.00kV (13.8kV)
24.00kV (16.5kV)
25.00kV (18.4kV)
30.0 kV (22kV)
45.0 kV (33kV)
90.0 kV (66kV)
120.0 kV (77kV)
5.00A
6.00A
7.50A
8.00A
10.00A
10.0A
12.00A
12.0A
15.00A
15.0A
1.00kA
1200A
1.20kA
1500A
1.50kA
1600A
1.60kA
1800A
1.80kA
2000A
2.00kA
2500A
2.50kA
3000A
3.00kA
4000A
4.00kA
5000A
5.00kA
6000A
15.00kA
15.0kA
20.00kA
20.0kA
30.00kA
30.0kA
250A
300.0A
300A
400A
500A
600A
750A
800A
900A
1000A
80.0A
100.0A
100A
120.0A
120A
150.0A
150A
200.0A
200A
250.0A
6.00kA
7500A
7.50kA
8000A
8.00kA
9.00kA
10.00kA
10.0kA
12.00kA
12.0kA
20.00A
20.0A
25.00A
25.0A
30.00A
30.0A
40.0A
50.0A
60.0A
75.0A
