SQLC-214-097
6
③ Voltage input
№ Setting item
3-phase 3-wire
Single-phase 3-wire
Single-phase
110V input 220V input 110V input 220V input
1 Display combination
Pattern Pattern 16 Pattern 16 Pattern 16
Main monitor V(UV) V(UN) V
Sub-monitor (Left) V(VW) V(WN) －
Sub-monitor (Center) V(WU) V(UW) －
Sub-monitor (Right) Hz Hz Hz
Bar graph V(UV) V(UN) V
2
Alarm
output
(
９
)
Alarm 1
Factor V V V
Reset form AUTO AUTO AUTO
Contact delay time 0 second 0 second 0 second
Test － － －
Alarm 2
Factor V V V
Reset form AUTO AUTO AUTO
Contact delay time 0 second 0 second 0 second
Test － － －
3
Harmonic
detection
Voltage
Distortion-factor upper limit OFF OFF OFF
5th conversion content rate
upper limit
OFF OFF OFF
n-th content rate
Factor 5th 5th 5th
Upper limit OFF OFF OFF
5th conversion detection characteristics
Inverse-time-delay
mode
Inverse-time-delay
mode
Inverse-time-delay
mode
Average value time limit 0 minute 0 minute 0 minute
4
Instant measurement
detection
Voltage upper limit value OFF OFF OFF
Voltage lower limit value OFF OFF OFF
5
Leakage detection
(
９
)
Rated sensitivity current 0.1A 0.1A 0.1A
Factor switching Io Io Io
Circuit switching 1 phase earthing 1 phase earthing 1 phase earthing
Use ZCT selection Type 0 Type 0 Type 0
6 Backlight
Action AUTO AUTO AUTO
Brightness 3（Middle） 3（Middle） 3（Middle）
7 Measurement range
Voltage range 6600V 220V 110.0V 3300V 220V
Frequency range 45‐65Hz 45‐65Hz 45‐65Hz
8
Analog output
(
９
)
Output factor 1 V(UV) V(UN) V
Output factor 2 V(VW) V(WN) －
Output factor 3 V(WU) V(UW) －
Output factor 4 Hz Hz Hz
Low input cut OFF OFF OFF
9
External operation
input (
９
)
Input 1 function Alarm reset Alarm reset Alarm reset
Input 2 function Max./Min. reset Max./Min. reset Max./Min. reset
10
Measurement display
ON/OFF
Voltage ON ON ON
Frequency ON ON ON
Harmonic voltage ON ON ON
Current leakage (
９
) ON ON ON
11 Input circuit
Phase line change (
11
) 3φ3W 1φ3W (U-N-W) 1φ2W
Input voltage (
12
) 110V 220V 300V 110V 220V
12 Measurement
Dead band 0.0％ 0.0％ 0.0％
Tidal current measurement General measurement General measurement General measurement
15 Analog output specification (
９
)(
10
) 1‐5V 1‐5V 1‐5V
16
Analog output
adjustment
(
９
)
Output 1
Bias adjustment 0.0％ 0.0％ 0.0％
Span adjustment 100.0％ 100.0％ 100.0％
Output 2
Bias adjustment 0.0％ 0.0％ 0.0％
Span adjustment 100.0％ 100.0％ 100.0％
Output 3
Bias adjustment 0.0％ 0.0％ 0.0％
Span adjustment 100.0％ 100.0％ 100.0％
Output 4
Bias adjustment 0.0％ 0.0％ 0.0％
Span adjustment 100.0％ 100.0％ 100.0％
Note(
９
) A setting item is not displayed in case there is no corresponding option.
The external operation input constitutes default value with an alarm-output option.
It becomes the next function in case there is no alarm-output option. Input 1 function：Max. / Min. reset,
Input 2 function：Measurement factor change.
Note(
10
) A setting item is not displayed if analog output is except DC0-5V (or DC1-5V) specification,
And analog output insulation product does not display a setting item.
Note(
11
) When the setting of phase line change of an input circuit is changed, it will return to the default value
of phase line which all set value changed.
Note(
12
) When phase line change setting of an input circuit is set as 3φ3W (or 1φ2W) and the input voltage setting
is changed, the voltage range returns to the default value of the phase line.
(For example：In case of 3φ3W, 6600V at the case of 110V setting, 300V at the case of 220V setting.）
