Daiichi Electronics SQLC-110L - Optional Features

SQLC-214-097
75
6.3 Option
Item Specification
Analog output
Number of output 4 circuits
Output
specification
Analog output non-insulation type Analog output insulation type
DC4‐20mA (Below 550Ω)
DC0‐1mA (Below 10kΩ)
DC0‐5V/1‐5V (Over 600Ω)
DC0‐10V (Over 2kΩ)
One of them is designated by identical
ratings.
DC4‐20mA (Below 550Ω)
DC1‐5V (Over 600Ω)
One of them is designated by identical
ratings.
Output factor
Voltage(UV-VW-WU)，Current(U-V-W)，Demand current(U-V-W)，Active power，
Demand active power，Reactive power，Power factor，Frequency，
Current leakage (Only with leakage measurement)，Distortion factor(A，V)，
Fundamental-wave effective value (Maximum value of each A/V phase)，
Harmonic 5th conversion content (Maximum value of each A/V phase)，
Harmonic 5th conversion effective value (Maximum value of each A/V phase)，
Harmonic nth content (Maximum value of each A/V phase)，
nth harmonic effective value (Maximum value of each A/V phase)
Response time
1 second or less (Time within ±1％ of final constant value.)
Leakage measurement is 2 seconds or less. Harmonic measurement is 10 seconds or less.
Output ripple Within the double precision of accuracy (％ for output span)
Pulse output
(
60
)
Possible output ：Watt-hour or var-hour.
Output form ：Optical MOS-FET relay. 1a contact
Contact capacity：AC，DC125V, 70mA (Resistance load, inductive load)
Pulse width ：250±10ms (Output pulse width when the output pulse period of rated active power
constitutes speed more than 2 pulse/second by setting of an voltage
measurement range, a current-measurement range, and an output pulse unit
is set to 100 to 130ms.)
Setting of output pulse unit is possible by the next range.
■ 3-phase 3-wire ：Full load power (kW,kvar)＝√3×Rated voltage(V)×Rated current(A)×10
-3
■ Single-phase 3-wire：Full load power (kW,kvar)＝2×Rated voltage(V)×Rated current(A)×10
-3
■ Single-phase 2-wire：Full load power (kW,kvar)＝Rated voltage(V)×Rated current(A)×10
-3
Full load power (kW,kvar) Output pulse unit. kWh(kvarh)/pulse Multiplying factor
Below 1 0.1 0.01 0.001 0.0001 0.01 (
59
)
Over 1 Below 10 1 0.1 0.01 0.001 0.1
Over 10 Below 100 10 1 0.1 0.01 1
Over 100 Below 1,000 100 10 1 0.1 10
Over 1,000 Below 10,000 1,000 100 10 1 100
Over 10,000 Below 100,000 10,000 1,000 100 10 1,000
Over 100,000 Below 1,000,000 100,000 10,000 1,000 100 10,000
Note(
59
) Although multiplying factor is 0.01, a multiplying factor display will be 0.1.
(The place by the integer is 4 digits display. An enlarged display is 4 digits below decimal point.)
Note(
60
) 2 outputs combination is possible, for pulse output and alarm output and CPU error output.
(CPU error output is 1 point only)
