Item Specification
Alarm output
(
61
)
Alarm factor：Demand current, Demand active power, Current leakage，harmonic 5th conversion content,
Harmonic nth content, Distortion factor, Voltage, Alarm OFF.
Possible to setting one of them.
Reset form ：Automatic reset or Manual reset (Setting)
Output contact ：No-voltage a contact (OR of each phase detection)
Contact capacity：AC250V 8A, DC125V 0.3A (Resistance load) AC250V 2A, DC125V 0.1A (Inductive load)
Alarm factor Item Specification
Demand current,
Demand active
power
Function
Demand measurement value ≧ Upper limit setting value,
Alarm display, Alarm output.
Setting accuracy ±1.0％ (％ for full scale )
Setting range 5 to 100％ to the maximum scale. (1％ step)
Current leakage
Only with
leakage
measurement
Sensitivity current 50 to 100％ (％ for rated sensitivity current value)
Rated sensitivity
current value
0.03A / 0.05A / 0.1A / 0.2A / 0.4A / 0.8A
Operating time Time-delay type (It exceeds 0.1 seconds and is 2 or less seconds.)
Test function
The functional test of the current-leakage detection by the test
mode is possible.
Harmonic 5th
conversion
content
Harmonic nth
content
Distortion
factor
Function
Measurement value ≧ Upper limit setting value,
Alarm display, Alarm output. (Detects by the maximum phase)
Setting accuracy Current：±2.5％, Voltage：±1.0％, ％ to 100％ of content rate.
Setting range
Current
Harmonic 5th conversion content, Harmonic nth content
(n=3,4,5,7,9,11,13,15), Distortion factor.
5 to 100％ (1％ step)
Voltage
Harmonic 5th conversion content, Harmonic nth content
(n=3,4,5,7,9,11,13,15), Distortion factor.
1.0 to 20.0％ (0.1％ step)
Detection
characteristics
Average value mode：It will detect, if a par measurement value
becomes beyond the above setting.
Inverse-time-delay mode：It detects in the inverse-time-delay
characteristics of instantaneous value (only a harmonic 5th
conversion content is possible).
Voltage
Function
Measurement value ≧ Upper limit setting value,
Alarm display, Alarm output. (Detects by the maximum phase)
Measurement value ≦ Lower limit setting value,
Alarm display, Alarm output. (Detects by the minimum phase)
Setting accuracy ±1.0％ (％ for full scale)
Setting range Using a full scale as 150％. 30 to 150％ (1％ step)
CPU error
output
(
61
)
Detection item (Self-diagnostics item) Contact composition Contact capacity
(1) Watchdog timer (Inside, outside)
(2) RAM check error
(3) A/D-conversion error
At the case of error detection and not applying for
auxiliary supply, an output is ON.
It becomes OR output of a detection item.
b contact
AC250V 5A, DC125V 0.2A
(Resistance load)
AC250V 1.5A, DC125V 0.1A
(Inductive load)
External
operation
input
Number of circuits 2 circuits, A function (four types) is changed by setting.
Function
Four types of following functions can be operated by adding a voltage signal
from the outside in addition to switch operation.
Alarm reset Alarm output is reset (output OFF).
Maximum / Minimum
value reset
The maximum/minimum value is reset (it updates to the instantaneous value at
the time).
Measurement factor
change
The measurement display element of the main monitoring is changed.
Phase change A phase/lines display of all the current/voltage currently displayed is changed.
Minimum operation pulse
width
300ms ，Continuation applying is possible.
Rated input
Input rating becomes the same as that of auxiliary supply.
(1) AC100/110V 0.4VA，AC200/220V 1.4VA，DC100/110V 0.4W AC DC two ways.
Contact capacity：About 3mA (AC,DC100/110V) ，About 6mA (AC200/220V)
(2) DC24V 0.3W，DC48V 1.2W
Contact capacity : About 10mA (DC24V) ，About 20mA (DC48V)
Note (
61
) 2 outputs combination is possible, for pulse output and alarm output and CPU error output.
(CPU error output is 1 point only)
