therMostat ConneCtions
IM 930-6 •EnnityVerticalWaterSourceHeatPumps 30 www.DaikinApplied.com
MicroTech III Wall-Mounted Room
Temperature Sensors (Kit P/N
669529101, 669529201, 669529001)
Figure 25: MicroTech III Wall-Mounted Room Temperature
Sensors (669529201 Not Shown)
Sensor669529101
Sensor669529201NotShown
Sensor669529001
General
MicrotechIIIWall-MountedRoomTemperatureSensors
provideelectronicsensingofroomtemperaturesat
walllocations.Allsensormodelsfeatureathermistor
(10kΩ)andagreenLEDforunitstatus.Tenantoverride,
setpointadjustmentpotentiometer,thermometer,anda
communicationsportareoptionalfeaturesavailablein
anycombination
Thismanualprovidesgeneralinformationforthe
MicrotechIIIWall-MountedRoomTemperatureSensors.
ForinstallationinstructionsrefertoIM955
Figure 26: MicroTech III Wall Sensor Details
FanControl
SlideSwitch
Mode Control
SlideSwitch
StatusLED
(Green)
0to1.5Kohm
Potentiometer
TenantOverrideMomentary
PushButtonSwitch
4.59"
3.75"
Specications
• Thermistorresistance(10kΩ)
• (Conformstoadvancethermalproductscurve2)
• AmbientTemperatureLimits:
• ShippingandStorage:40°Fto160°F(–40°Cto71°C)
• Operating:40°Fto140°F(4°Cto60°C)
• Humidity:5to95%RH,non-condensing
• Locations:NEMAType1,Indooronly
• Connections:ColorCodedLeads
Wiring Sensors to the MicroTech III
Unit Controller
Figure 27: Temperature Sensor Wiring to MicroTech III
Unit Controller (669529101, 669529201)
Temperature
SensorTerminals
MicroTechIIIUnit
ControllerTB1Terminals
Figure 28: Temperature Sensor Wiring to MicroTech III
Unit Controller (669529001)
MicroTechIIIUnit
ControllerTB1Terminals
Temperature
SensorTerminals
