Engineering Data – R22 MODEL
MODEL
INDOOR UNIT FL15EXV1 FL20EXV1 FL25EXV1
OUTDOOR UNIT R15CXV1 R20CXV1 R25CXV1
NOMINAL COOLING CAPACITY
Btu/h 12000 19000 24000
W 3520 5570 7030
NOMINAL TOTAL INPUT POWER (COOLING) W 1288 1861 2573
NOMINAL RUNNING CURRENT (COOLING) A 5.80 8.20 12.0
EER W/W 2.73 2.99 2.73
REFRIGERANT CONTROL (EXPANSION DEVICE) OUTDOOR CAP TUBE
REFRIGERANT CHARGE kg 0.75 1.35 1.50
MODEL
INDOOR UNIT FLY15EXV1 FLY20EXV1 FLY20EXV1 FLY25EXV1
OUTDOOR UNIT RY15CXV1 RY18CXV1 RY20CXV1 RY25CXV1
NOMINAL COOLING CAPACITY
Btu/h 12000 18000 19000 24000
W 3520 5280 5570 7030
NOMINAL HEATING CAPACITY
Btu/h 12000 18500 19500 25000
W 3520 5420 5720 7330
NOMINAL TOTAL INPUT POWER (COOLING) W 1288 1872 1861 2573
NOMINAL TOTAL INPUT POWER (HEATING) W 998 1710 1811 2493
NOMINAL RUNNING CURRENT (COOLING) A 5.80 8.25 8.20 12.0
NOMINAL RUNNING CURRENT (HEATING) A 4.50 7.70 8.00 11.7
EER W/W 2.73 2.82 2.99 2.73
COP W/W 3.52 3.17 3.16 2.94
REFRIGERANT CONTROL (EXPANSION DEVICE) OUTDOOR CAP TUBE
REFRIGERANT CHARGE kg 0.925 0.85 1.35 1.50
POWER SOURCE V/Ph/Hz 220-240 / 1 / 50
REFRIGERANT TYPE R22
INDOOR UNIT
CONTROL
AIR DISCHARGE AUTOMATIC LOUVER (UP & DOWN)
OPERATION WIRELESS OR WIRED REMOTE CONTROL
AIR FLOW
HIGH l/s / CFM 240 / 508 245 / 520 374 / 580
MEDIUM l/s / CFM 182 / 386 217 / 460 250 / 530
LOW l/s / CFM 165 / 350 192 / 406 231 / 490
EXTERNAL STATIC PRESSURE Pa (in.wg.) 0
SOUND PRESSURE LEVEL (H/M/L) dBA 48 / 43 / 41 48 / 46 / 43 50 / 47 / 46
UNIT DIMENSION HEIGHT X WIDTH X DEPTH mm 218 x 1080 x 630
PACKING DIMENSION HEIGHT X WIDTH X DEPTH mm 297 x 1197 x 740
UNIT WEIGHT kg 26 27 27
CONDENSATE DRAIN SIZE mm 19.1 / 3/4
FAN
TYPE BLOWER WHEEL
DRIVE DIRECT
FAN MOTOR
TYPE INDUCTION
INDEX OF PROTECTION (IP) 20
INSULATION GRADE B
RATED INPUT POWER W 84 86 139
RATED RUNNING CURRENT A 0.37 0.38 0.68
MOTOR OUTPUT W 40 50 65
POLES 4
COIL
TUBE
MATERIAL COPPER
DIAMETER mm 7.00
FIN
MATERIAL ALUMINIUM
FACE AREA m
2
0.27
ROW 223
AIR QUALITY FILTER
TYPE SARANET
QUANTITY pc 2
CASING COLOUR LIGHT GREY
OUTDOOR UNIT
AIR FLOW l/s / CFM 453 / 960 614 / 1300 614 / 1300 755 / 1600
SOUND PRESSURE LEVEL dBA 49 51 51 52
UNIT DIMENSION HEIGHT X WIDTH X DEPTH mm 540 x 700 x 250 651 x 855 x 328 651 x 855 x 328 753 x 855 x 328
PACKING DIMENSION HEIGHT X WIDTH X DEPTH mm 620 x 810 x 330 710 x 990 x 415 710 x 990 x 415 810 x 990 x 415
UNIT WEIGHT
COOLING ONLY
kg
28 -
47 57
HEATPUMP 30 43
PIPE
CONNECTION
TYPE FLARE VALVE
SIZE
LIQUID mm 6.35 6.35 6.35 9.52
GAS mm 12.7 15.88 15.88 15.88
FAN
TYPE PROPPELER
DRIVE DIRECT
FAN MOTOR
TYPE INDUCTION
INDEX OF PROTECTION (IP) 23
INSULATION GRADE BFFF
RATED INPUT POWER W 76 81 80 119
RATED RUNNING CURRENT A 0.33 0.36 0.35 0.52
MOTOR OUTPUT W 30 32 32 60
POLES 6
COMPRESSOR
TYPE ROTARY
OIL TYPE ATMOS NM56M / SUNISO 4GDID
OIL AMOUNT cm
3
350 670 670 700
RATED INPUT POWER (COOLING) W 1128 1705 1695 2315
RATED INPUT POWER (HEATING) W 838 1543 1645 2235
RATED RUNNING CURRENT (COOLING) A 5.10 7.51 7.47 10.8
RATED RUNNING CURRENT (HEATING) A 3.80 6.96 7.27 10.5
LOCKED ROTOR AMP. A 25 34 34 56
COIL
TUBE
MATERIAL COPPER
R DIAMETER mm 7.00 7.00 7.00 7.00
RY DIAMETER mm 9.52 7.00 7.00 7.00
FIN
MATERIAL ALUMINIUM
FACE AREA m
2
0.36 0.52 0.52 0.62
ROW 1122
CASING COLOUR LIGHT GREY
ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151 (NON-DUCTED UNIT) OR ISO 13253 (DUCTED UNIT).
COOLING HEATING
INDOOR: 27°C DB / 19°C WB INDOOR: 20°C DB
OUTDOOR: 35°C DB / 24°C WB OUTDOOR: 7°C DB / 6°C WB
