Daikin FL15EXV1 - Model

38
Performance Data
Model: FLY20EXV1 - RY20CXV1
Cooling Mode
AFR
(CFM)
EWB EDB
Outdoor temperature
19°C 25°C 30°C 35°C 40°C 46°C
TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI
406
16°C
21°C 5.25 3.51 1.41 5.07 3.42 1.53 4.88 3.33 1.66 4.68 3.23 1.79 4.30 3.01 1.95 3.97 2.83 2.15
24°C 5.26 4.21 1.41 5.07 4.11 1.53 4.88 4.02 1.66 4.69 3.92 1.80 4.31 3.66 1.95 3.98 3.45 2.15
27°C 5.30 4.77 1.42 5.12 4.66 1.53 4.94 4.55 1.66 4.76 4.44 1.80 4.39 4.13 1.95 4.08 3.88 2.16
30°C 5.46 5.46 1.42 5.31 5.31 1.54 5.15 5.15 1.67 4.98 4.98 1.81 4.62 4.62 1.97 4.32 4.32 2.18
19°C
24°C 5.79 3.28 1.44 5.59 3.20 1.55 5.39 3.11 1.68 5.17 3.02 1.83 4.75 2.82 1.98 4.39 2.65 2.18
27°C 5.80 3.75 1.44 5.59 3.67 1.55 5.39 3.59 1.68 5.18 3.50 1.83 4.76 3.27 1.98 4.40 3.10 2.18
30°C 5.81 4.63 1.44 5.61 4.53 1.56 5.41 4.43 1.69 5.20 4.33 1.83 4.79 4.05 1.98 4.44 3.83 2.19
33°C 5.88 5.88 1.44 5.68 5.68 1.56 5.50 5.50 1.69 5.31 5.31 1.84 4.91 4.91 1.99 4.59 4.59 2.20
22°C
27°C 6.37 3.21 1.46 6.15 3.13 1.58 5.93 3.05 1.72 5.70 2.97 1.86 5.24 2.77 2.02 4.85 2.61 2.23
30°C 6.38 3.91 1.46 6.16 3.83 1.58 5.93 3.74 1.72 5.70 3.65 1.86 5.24 3.42 2.02 4.85 3.24 2.23
33°C 6.38 4.57 1.46 6.16 4.48 1.58 5.93 4.39 1.72 5.70 4.30 1.86 5.25 4.04 2.02 4.86 3.84 2.23
36°C 6.40 5.18 1.46 6.19 5.08 1.59 5.97 4.97 1.72 5.76 4.86 1.87 5.31 4.56 2.03 4.94 4.33 2.23
460
16°C
21°C 5.46 3.66 1.43 5.27 3.57 1.54 5.07 3.48 1.67 4.86 3.38 1.81 4.46 3.14 1.96 4.11 2.96 2.16
24°C 5.48 4.45 1.43 5.28 4.34 1.54 5.09 4.24 1.67 4.88 4.13 1.81 4.48 3.86 1.97 4.14 3.64 2.17
27°C 5.55 5.05 1.43 5.36 4.93 1.55 5.18 4.81 1.68 4.99 4.66 1.82 4.61 4.33 1.97 4.29 4.05 2.18
30°C 5.78 5.78 1.44 5.61 5.61 1.56 5.44 5.44 1.69 5.26 5.26 1.84 4.88 4.88 2.00 4.56 4.56 2.20
19°C
24°C 6.02 3.47 1.45 5.81 3.38 1.57 5.59 3.29 1.70 5.36 3.20 1.84 4.93 2.98 2.00 4.55 2.81 2.20
27°C 6.03 3.99 1.45 5.82 3.90 1.57 5.60 3.82 1.70 5.37 3.73 1.84 4.94 3.48 2.00 4.56 3.30 2.20
30°C 6.06 4.93 1.45 5.85 4.82 1.57 5.64 4.71 1.70 5.42 4.60 1.85 4.99 4.30 2.00 4.63 4.06 2.21
33°C 6.16 6.16 1.46 5.97 5.97 1.58 5.78 5.78 1.71 5.59 5.59 1.86 5.18 5.18 2.02 4.84 4.84 2.23
22°C
27°C 6.61 3.39 1.48 6.38 3.31 1.60 6.14 3.23 1.73 5.90 3.14 1.88 5.42 2.93 2.04 5.01 2.77 2.25
30°C 6.62 4.16 1.48 6.39 4.08 1.60 6.15 3.99 1.73 5.91 3.89 1.88 5.43 3.65 2.04 5.02 3.46 2.25
33°C 6.63 4.88 1.48 6.40 4.79 1.60 6.17 4.69 1.74 5.93 4.59 1.88 5.45 4.31 2.04 5.05 4.09 2.25
36°C 6.68 5.52 1.48 6.46 5.41 1.60 6.23 5.30 1.74 6.01 5.18 1.89 5.54 4.84 2.05 5.17 4.57 2.26
520
16°C
21°C 5.67 3.82 1.44 5.46 3.73 1.55 5.25 3.63 1.68 5.03 3.53 1.83 4.62 3.28 1.98 4.25 3.09 2.18
24°C 5.70 4.65 1.44 5.49 4.54 1.56 5.28 4.42 1.69 5.07 4.31 1.83 4.66 4.02 1.98 4.30 3.79 2.19
27°C 5.79 5.32 1.44 5.60 5.19 1.56 5.41 5.04 1.69 5.22 4.89 1.84 4.82 4.53 1.99 4.49 4.23 2.20
30°C 6.08 6.08 1.46 5.90 5.90 1.58 5.72 5.72 1.71 5.53 5.53 1.86 5.12 5.12 2.02 4.78 4.78 2.23
19°C
24°C 6.24 3.67 1.46 6.01 3.58 1.58 5.78 3.49 1.71 5.55 3.39 1.86 5.09 3.16 2.02 4.70 2.98 2.22
27°C 6.26 4.24 1.46 6.03 4.15 1.58 5.80 4.05 1.72 5.57 3.95 1.86 5.11 3.69 2.02 4.73 3.49 2.22
30°C 6.31 5.22 1.47 6.08 5.11 1.59 5.87 4.99 1.72 5.64 4.87 1.86 5.19 4.54 2.02 4.82 4.28 2.23
33°C 6.44 6.44 1.47 6.26 6.26 1.60 6.06 6.06 1.73 5.86 5.86 1.88 5.43 5.43 2.04 5.08 5.08 2.25
22°C
27°C 6.84 3.59 1.49 6.60 3.51 1.61 6.35 3.42 1.75 6.10 3.33 1.90 5.60 3.11 2.06 5.18 2.94 2.26
30°C 6.86 4.42 1.49 6.61 4.34 1.61 6.37 4.24 1.75 6.11 4.15 1.90 5.61 3.88 2.06 5.19 3.68 2.27
33°C 6.88 5.18 1.49 6.64 5.09 1.62 6.40 4.99 1.75 6.15 4.88 1.90 5.66 4.57 2.06 5.24 4.34 2.27
36°C 6.94 5.85 1.49 6.73 5.75 1.62 6.49 5.62 1.76 6.26 5.48 1.91 5.78 5.11 2.07 5.40 4.81 2.28
Model: FLY20EXV1 - RY20CXV1
Heating Mode
ID DB
Outdoor WB
-9°C -6°C -5°C 6°C 12°C 15°C 18°C
TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW)
15°C 3.455 3.455 3.910 3.910 4.062 4.062 5.732 5.732 6.643 6.643 7.099 7.099 7.554 7.554
17°C 3.364 3.364 3.869 3.869 3.976 3.976 5.725 5.725 6.574 6.574 7.032 7.032 7.491 7.491
19°C 3.274 3.274 3.827 3.827 3.889 3.889 5.719 5.719 6.504 6.504 6.966 6.966 7.427 7.427
21°C 3.183 3.183 3.747 3.747 3.803 3.803 5.653 5.653 6.435 6.435 6.899 6.899 7.364 7.364
23°C 3.093 3.093 3.626 3.626 3.716 3.716 5.528 5.528 6.366 6.366 6.833 6.833 7.301 7.301
25°C 3.002 3.002 3.506 3.506 3.630 3.630 5.404 5.404 6.296 6.296 6.767 6.767 7.237 7.237
27°C 2.912 2.912 3.385 3.385 3.543 3.543 5.280 5.280 6.227 6.227 6.700 6.700 7.174 7.174
Frost Region
Remark:
AFR: Air fl ow rate (CFM)
EWB: Entering Wet Bulb Temp. (°C)
EDB: Entering Dry Bulb Temp. (°C)
TC: Total Cooling / Heating Capacity (kW)
SC: Sensible Cooling / Heating Capacity (kW)
PI: Power Input (kW)
Notes:
1. Ratings shown are net capacities.
2. shows nominal capacities.
3. Direct interpolation is permissible. Do not extrapolate.
4. Unit is able to operate at ambient from 19°C to 46°C DB (cooling) / -9°C to 18°C WB (heating) without pressure trip.
