Performance Data
Model: FLY50EXV1 - RY50DXY1
Cooling Mode
AFR
(CFM)
EWB EDB
Outdoor temperature
19°C 25°C 30°C 35°C 40°C 46°C
TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI
959
16°C
21°C
12.73
8.41 3.61
12.28
8.19 3.90
11.82
7.97 4.23
11.35
7.74 4.58
10.42
7.20 4.97 9.62 6.77 5.48
24°C
12.75 10.07
3.61
12.29
9.84 3.90
11.84
9.61 4.23
11.37
9.37 4.59
10.44
8.75 4.97 9.66 8.26 5.48
27°C
12.85 11.41
3.62
12.42 11.16
3.91
11.98 10.89
4.24
11.53 10.61
4.60
10.64
9.88 4.99 9.90 9.28 5.51
30°C
13.24 13.24
3.63
12.86 12.86
3.93
12.47 12.47
4.27
12.07 12.07
4.63
11.19 11.19
5.03
10.47 10.47
5.56
19°C
24°C
14.04
7.85 3.67
13.55
7.65 3.97
13.05
7.45 4.30
12.54
7.24 4.66
11.52
6.74 5.06
10.65
6.35 5.58
27°C
14.05
8.98 3.67
13.56
8.78 3.97
13.06
8.58 4.30
12.55
8.37 4.67
11.53
7.83 5.06
10.66
7.42 5.58
30°C
14.07 11.08
3.67
13.59 10.85
3.97
13.11 10.61
4.30
12.61 10.35
4.67
11.61
9.68 5.07
10.77
9.16 5.59
33°C
14.24 14.24
3.68
13.78 13.78
3.98
13.33 13.33
4.32
12.87 12.87
4.69
11.91 11.91
5.09
11.14 11.14
5.62
22°C
27°C
15.45
7.68 3.73
14.91
7.50 4.04
14.37
7.31 4.38
13.81
7.11 4.76
12.70
6.62 5.16
11.75
6.24 5.68
30°C
15.45
9.36 3.73
14.92
9.16 4.04
14.37
8.96 4.38
13.81
8.74 4.76
12.70
8.18 5.16
11.76
7.76 5.68
33°C
15.46 10.93
3.73
14.93 10.73
4.04
14.38 10.51
4.39
13.82 10.30
4.76
12.72
9.67 5.16
11.79
9.18 5.69
36°C
15.51 12.40
3.74
15.00 12.15
4.05
14.48 11.90
4.39
13.95 11.64
4.77
12.87 10.91
5.17
11.96 10.35
5.70
1082
16°C
21°C
13.24
8.77 3.64
12.77
8.54 3.94
12.28
8.31 4.26
11.78
8.08 4.62
10.81
7.52 5.02 9.97 7.08 5.53
24°C
13.28 10.64
3.64
12.81 10.39
3.94
12.33 10.14
4.27
11.83
9.89 4.63
10.87
9.23 5.02
10.05
8.71 5.53
27°C
13.44 12.09
3.65
12.99 11.80
3.95
12.54 11.50
4.28
12.09 11.16
4.65
11.17 10.36
5.04
10.40
9.69 5.57
30°C
14.00 14.00
3.68
13.60 13.60
3.98
13.18 13.18
4.32
12.76 12.76
4.69
11.82 11.82
5.10
11.05 11.05
5.63
19°C
24°C
14.59
8.29 3.70
14.07
8.09 4.01
13.54
7.87 4.34
13.00
7.66 4.71
11.94
7.14 5.10
11.03
6.73 5.62
27°C
14.62
9.55 3.70
14.10
9.34 4.01
13.57
9.13 4.34
13.02
8.91 4.71
11.97
8.33 5.11
11.06
7.89 5.63
30°C
14.69 11.78
3.71
14.18 11.53
4.01
13.67 11.27
4.35
13.15 11.00
4.72
12.10 10.28
5.12
11.23
9.71 5.64
33°C
14.93 14.93
3.72
14.48 14.48
4.03
14.01 14.01
4.37
13.55 13.55
4.75
12.55 12.55
5.16
11.73 11.73
5.69
22°C
27°C
16.03
8.12 3.77
15.47
7.93 4.08
14.89
7.73 4.43
14.30
7.52 4.80
13.14
7.01 5.21
12.15
6.62 5.73
30°C
16.05
9.96 3.77
15.49
9.76 4.08
14.91
9.54 4.43
14.32
9.32 4.80
13.16
8.73 5.21
12.17
8.28 5.74
33°C
16.08 11.68
3.77
15.52 11.45
4.09
14.95 11.22
4.43
14.36 10.98
4.81
13.21 10.30
5.21
12.25
9.78 5.74
36°C
16.18 13.20
3.78
15.66 12.95
4.10
15.11 12.68
4.44
14.56 12.38
4.82
13.43 11.59
5.23
12.52 10.93
5.77
1215
16°C
21°C
13.73
9.15 3.67
13.23
8.92 3.97
12.72
8.68 4.30
12.20
8.44 4.66
11.19
7.86 5.05
10.31
7.40 5.57
24°C
13.81 11.12
3.68
13.30 10.85
3.98
12.80 10.59
4.31
12.29 10.31
4.67
11.28
9.62 5.06
10.42
9.07 5.58
27°C
14.03 12.74
3.69
13.57 12.41
3.99
13.11 12.06
4.32
12.64 11.69
4.69
11.68 10.83
5.09
10.89 10.11
5.62
30°C
14.73 14.73
3.72
14.30 14.30
4.03
13.86 13.86
4.37
13.40 13.40
4.74
12.41 12.41
5.15
11.59 11.59
5.69
19°C
24°C
15.12
8.77 3.73
14.57
8.56 4.04
14.02
8.34 4.38
13.45
8.11 4.75
12.34
7.56 5.15
11.39
7.13 5.67
27°C
15.16 10.15
3.73
14.62
9.92 4.04
14.07
9.69 4.38
13.50
9.45 4.75
12.40
8.84 5.15
11.46
8.36 5.68
30°C
15.29 12.49
3.74
14.75 12.22
4.05
14.22 11.94
4.39
13.67 11.64
4.76
12.59 10.87
5.17
11.69 10.25
5.70
33°C
15.62 15.62
3.76
15.16 15.16
4.07
14.69 14.69
4.42
14.21 14.21
4.80
13.16 13.16
5.22
12.31 12.31
5.76
22°C
27°C
16.59
8.58 3.80
16.00
8.40 4.12
15.40
8.18 4.46
14.78
7.97 4.84
13.57
7.44 5.25
12.54
7.02 5.78
30°C
16.62 10.58
3.80
16.03 10.38
4.12
15.43 10.16
4.47
14.81
9.92 4.84
13.60
9.29 5.25
12.58
8.81 5.78
33°C
16.68 12.40
3.81
16.10 12.18
4.13
15.51 11.93
4.47
14.90 11.66
4.85
13.71 10.93
5.26
12.70 10.38
5.80
36°C
16.83 14.00
3.82
16.30 13.75
4.14
15.74 13.45
4.49
15.17 13.11
4.87
14.02 12.23
5.29
13.08 11.51
5.83
Model: FLY50EXV1 - RY50DXY1
Heating Mode
ID DB
Outdoor WB
-9°C -6°C -5°C 6°C 12°C 15°C 18°C
TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW)
15°C 9.189 9.189 10.400 10.400 10.804 10.804 15.245 15.245 17.668 17.668 18.879 18.879 20.091 20.091
17°C 8.948 8.948 10.240 10.240 10.583 10.583 15.227 15.227 17.532 17.532 18.759 18.759 19.985 19.985
19°C 8.707 8.707 10.080 10.080 10.362 10.362 15.209 15.209 17.397 17.397 18.638 18.638 19.879 19.879
21°C 8.466 8.466 9.864 9.864 10.141 10.141 15.064 15.064 17.261 17.261 18.517 18.517 19.773 19.773
23°C 8.225 8.225 9.591 9.591 9.920 9.920 14.793 14.793 17.125 17.125 18.396 18.396 19.668 19.668
25°C 7.984 7.984 9.318 9.318 9.700 9.700 14.522 14.522 16.989 16.989 18.275 18.275 19.562 19.562
27°C 7.743 7.743 9.045 9.045 9.479 9.479 14.250 14.250 16.853 16.853 18.155 18.155 19.456 19.456
Frost Region
Remark:
AFR: Air fl ow rate (CFM)
EWB: Entering Wet Bulb Temp. (°C)
EDB: Entering Dry Bulb Temp. (°C)
TC: Total Cooling / Heating Capacity (kW)
SC: Sensible Cooling / Heating Capacity (kW)
PI: Power Input (kW)
Notes:
1. Ratings shown are net capacities.
2. shows nominal capacities.
3. Direct interpolation is permissible. Do not extrapolate.
4. Unit is able to operate at ambient from 19°C to 46°C DB (cooling) / -9°C to 18°C WB (heating) without pressure trip.
