Performance Data
Model: FLY20EXV1 - RY18CXV1
Cooling Mode
AFR
(CFM)
EWB EDB
Outdoor temperature
19°C 25°C 30°C 35°C 40°C 46°C
TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI
406
16°C
21°C 4.98 3.24 1.42 4.80 3.15 1.54 4.62 3.07 1.66 4.44 2.98 1.80 4.08 2.77 1.96 3.76 2.61 2.16
24°C 4.99 3.88 1.42 4.81 3.79 1.54 4.63 3.70 1.66 4.45 3.61 1.81 4.08 3.37 1.96 3.78 3.18 2.16
27°C 5.02 4.40 1.42 4.86 4.30 1.54 4.69 4.20 1.67 4.51 4.09 1.81 4.16 3.80 1.96 3.87 3.57 2.17
30°C 5.18 5.18 1.43 5.03 5.03 1.55 4.88 4.88 1.68 4.72 4.72 1.82 4.38 4.38 1.98 4.09 4.09 2.19
19°C
24°C 5.49 3.02 1.44 5.30 2.95 1.56 5.10 2.87 1.69 4.90 2.79 1.84 4.51 2.60 1.99 4.17 2.44 2.20
27°C 5.50 3.46 1.44 5.30 3.38 1.56 5.11 3.30 1.69 4.91 3.22 1.84 4.51 3.02 1.99 4.17 2.86 2.20
30°C 5.50 4.27 1.44 5.31 4.18 1.56 5.13 4.09 1.69 4.93 3.99 1.84 4.54 3.73 1.99 4.21 3.53 2.20
33°C 5.57 5.57 1.45 5.39 5.39 1.57 5.21 5.21 1.70 5.04 5.04 1.85 4.66 4.66 2.00 4.36 4.36 2.21
22°C
27°C 6.04 2.96 1.47 5.83 2.89 1.59 5.62 2.82 1.73 5.40 2.74 1.87 4.97 2.55 2.03 4.60 2.41 2.24
30°C 6.04 3.61 1.47 5.83 3.53 1.59 5.62 3.45 1.73 5.40 3.37 1.87 4.97 3.15 2.03 4.60 2.99 2.24
33°C 6.05 4.21 1.47 5.84 4.13 1.59 5.63 4.05 1.73 5.41 3.97 1.87 4.97 3.72 2.03 4.61 3.54 2.24
36°C 6.07 4.78 1.47 5.87 4.68 1.59 5.66 4.58 1.73 5.46 4.48 1.88 5.03 4.20 2.04 4.68 3.99 2.24
460
16°C
21°C 5.18 3.38 1.43 4.99 3.29 1.55 4.80 3.20 1.68 4.61 3.11 1.82 4.23 2.90 1.97 3.90 2.73 2.18
24°C 5.20 4.10 1.43 5.01 4.00 1.55 4.82 3.91 1.68 4.63 3.81 1.82 4.25 3.55 1.98 3.93 3.35 2.18
27°C 5.26 4.66 1.44 5.08 4.55 1.56 4.91 4.43 1.69 4.73 4.30 1.83 4.37 3.99 1.99 4.07 3.73 2.19
30°C 5.48 5.48 1.45 5.32 5.32 1.57 5.16 5.16 1.70 4.99 4.99 1.85 4.62 4.62 2.01 4.32 4.32 2.21
19°C
24°C 5.71 3.19 1.46 5.50 3.11 1.58 5.30 3.03 1.71 5.08 2.95 1.85 4.67 2.75 2.01 4.31 2.59 2.21
27°C 5.72 3.68 1.46 5.51 3.60 1.58 5.31 3.52 1.71 5.09 3.43 1.85 4.68 3.21 2.01 4.33 3.04 2.22
30°C 5.74 4.54 1.46 5.54 4.44 1.58 5.35 4.34 1.71 5.14 4.24 1.86 4.73 3.96 2.01 4.39 3.74 2.22
33°C 5.84 5.84 1.46 5.66 5.66 1.59 5.48 5.48 1.72 5.30 5.30 1.87 4.91 4.91 2.03 4.59 4.59 2.24
22°C
27°C 6.27 3.13 1.48 6.05 3.05 1.61 5.82 2.98 1.74 5.59 2.90 1.89 5.14 2.70 2.05 4.75 2.55 2.26
30°C 6.28 3.84 1.48 6.06 3.76 1.61 5.83 3.67 1.74 5.60 3.59 1.89 5.15 3.36 2.05 4.76 3.19 2.26
33°C 6.29 4.50 1.48 6.07 4.41 1.61 5.85 4.32 1.74 5.62 4.23 1.89 5.17 3.97 2.05 4.79 3.77 2.26
36°C 6.33 5.08 1.49 6.12 4.99 1.61 5.91 4.88 1.75 5.69 4.77 1.90 5.25 4.46 2.06 4.90 4.21 2.27
520
16°C
21°C 5.37 3.52 1.45 5.17 3.43 1.56 4.98 3.34 1.69 4.77 3.25 1.83 4.37 3.03 1.99 4.03 2.85 2.19
24°C 5.40 4.28 1.45 5.20 4.18 1.57 5.01 4.08 1.70 4.81 3.97 1.84 4.41 3.71 1.99 4.08 3.49 2.20
27°C 5.49 4.91 1.45 5.31 4.78 1.57 5.13 4.65 1.70 4.94 4.50 1.85 4.57 4.17 2.01 4.26 3.89 2.21
30°C 5.76 5.76 1.46 5.59 5.59 1.59 5.42 5.42 1.72 5.24 5.24 1.87 4.85 4.85 2.03 4.53 4.53 2.24
19°C
24°C 5.91 3.38 1.47 5.70 3.30 1.59 5.48 3.21 1.72 5.26 3.12 1.87 4.83 2.91 2.03 4.46 2.75 2.23
27°C 5.93 3.91 1.47 5.72 3.82 1.59 5.50 3.73 1.72 5.28 3.64 1.87 4.85 3.40 2.03 4.48 3.22 2.23
30°C 5.98 4.81 1.47 5.77 4.71 1.59 5.56 4.60 1.73 5.35 4.48 1.87 4.92 4.19 2.03 4.57 3.95 2.24
33°C 6.11 6.11 1.48 5.93 5.93 1.60 5.75 5.75 1.74 5.56 5.56 1.89 5.15 5.15 2.05 4.81 4.81 2.27
22°C
27°C 6.49 3.31 1.50 6.26 3.23 1.62 6.02 3.15 1.76 5.78 3.07 1.91 5.31 2.86 2.07 4.91 2.70 2.28
30°C 6.50 4.08 1.50 6.27 4.00 1.62 6.03 3.91 1.76 5.79 3.82 1.91 5.32 3.58 2.07 4.92 3.39 2.28
33°C 6.52 4.78 1.50 6.30 4.69 1.62 6.07 4.59 1.76 5.83 4.49 1.91 5.36 4.21 2.07 4.97 4.00 2.28
36°C 6.58 5.39 1.50 6.38 5.30 1.63 6.16 5.18 1.77 5.93 5.05 1.92 5.48 4.71 2.08 5.11 4.44 2.30
Model: FLY20EXV1 - RY18CXV1
Heating Mode
ID DB
Outdoor WB
-9°C -6°C -5°C 6°C 12°C 15°C 18°C
TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW)
15°C 3.278 3.278 3.710 3.710 3.854 3.854 5.438 5.438 6.302 6.302 6.735 6.735 7.167 7.167
17°C 3.192 3.192 3.749 3.749 3.781 3.781 5.432 5.432 6.284 6.284 6.726 6.726 7.168 7.168
19°C 3.106 3.106 3.787 3.787 3.708 3.708 5.425 5.425 6.266 6.266 6.718 6.718 7.169 7.169
21°C 3.020 3.020 3.728 3.728 3.635 3.635 5.392 5.392 6.248 6.248 6.709 6.709 7.170 7.170
23°C 2.934 2.934 3.569 3.569 3.562 3.562 5.333 5.333 6.230 6.230 6.701 6.701 7.171 7.171
25°C 2.848 2.848 3.411 3.411 3.489 3.489 5.273 5.273 6.212 6.212 6.692 6.692 7.173 7.173
27°C 2.762 2.762 3.252 3.252 3.416 3.416 5.213 5.213 6.194 6.194 6.684 6.684 7.174 7.174
Frost Region
Remark:
AFR: Air fl ow rate (CFM)
EWB: Entering Wet Bulb Temp. (°C)
EDB: Entering Dry Bulb Temp. (°C)
TC: Total Cooling / Heating Capacity (kW)
SC: Sensible Cooling / Heating Capacity (kW)
PI: Power Input (kW)
Notes:
1. Ratings shown are net capacities.
2. shows nominal capacities.
3. Direct interpolation is permissible. Do not extrapolate.
4. Unit is able to operate at ambient from 19°C to 46°C DB (cooling) / -9°C to 18°C WB (heating) without pressure trip.
