Daikin SUPER MULTI NX G Series User Manual

EDUS121131 Specifications
SUPER MULTI NX 2/3/4MXS-G/J Series Heat Pump 45
1
Heating [60 Hz, 230 V]
Combination
of
indoor unit
Type of indoor unit
Capacity of each indoor unit
Each capacity (kBtu/h) Total capacity (kBtu/h) Total input (W) Total current (A)
Power
factor (%)
A room B room C room D room A room B room C room D room Rating ( min ~ max ) Rating ( min ~ max ) Rating ( min ~ max ) Rating
07 Wall — — — 8.80 — — — 8.80 5.40 ~ 9.50 1050 750 ~ 1150 4.7 3.3 ~ 5.1 98
09 Wall — — — 11.30 — — — 11.30 5.40 ~ 12.20 1300 750 ~ 1410 5.8 3.3 ~ 6.3 98
09 Duct — — — 10.70 — — — 10.70 5.50 ~ 11.60 1370 830 ~ 1480 6.1 3.7 ~ 6.6 98
12 Wall — — — 15.00 — — — 15.00 5.40 ~ 16.30 1740 750 ~ 1850 7.7 3.3 ~ 8.2 98
12 Duct — — — 14.30 — — — 14.30 5.50 ~ 15.30 1770 830 ~ 1890 7.9 3.7 ~ 8.4 98
15 Wall — — — 18.80 — — — 18.80 5.20 ~ 20.30 1970 690 ~ 2190 8.7 3.1 ~ 9.7 98
15 Duct — — — 17.80 — — — 17.80 5.30 ~ 18.60 2140 860 ~ 2260 9.5 3.8 ~ 10.0 98
18 Wall — — — 22.50 — — — 22.50 5.10 ~ 24.40 2420 680 ~ 2770 10.7 3.0 ~ 12.3 98
18 Duct — — — 18.80 — — — 18.80 5.30 ~ 19.20 2260 860 ~ 2320 10.0 3.8 ~ 10.3 98
07+07 Wall Wall — — 8.75 8.75 — — 17.50 4.90 ~ 19.10 1580 630 ~ 1720 7.0 2.8 ~ 7.6 98
07+09 Wall Wall — — 8.89 11.11 — — 20.00 4.90 ~ 22.00 1820 630 ~ 2060 8.1 2.8 ~ 9.1 98
07+09 Wall Duct — — 8.67 10.83 — — 19.50 5.00 ~ 21.50 1910 690 ~ 2160 8.5 3.1 ~ 9.6 98
07+12 Wall Wall — — 8.65 15.15 — — 23.80 4.90 ~ 25.30 2310 630 ~ 2530 10.2 2.8 ~ 11.2 98
07+12 Wall Duct — — 8.44 14.76 — — 23.20 5.00 ~ 25.10 2430 690 ~ 2710 10.8 3.1 ~ 12.0 98
07+15 Wall Wall — — 7.86 19.64 — — 27.50 6.00 ~ 29.90 2610 650 ~ 3040 11.6 2.9 ~ 13.5 98
07+15 Wall Duct — — 7.66 19.14 — — 26.80 6.10 ~ 28.80 2850 810 ~ 3180 12.6 3.6 ~ 14.1 98
07+18 Wall Wall — — 7.55 22.65 — — 30.20 7.10 ~ 32.60 3050 700 ~ 3620 13.5 3.1 ~ 16.1 98
07+18 Wall Duct — — 7.38 22.12 — — 29.50 7.30 ~ 31.40 3360 880 ~ 3840 14.9 3.9 ~ 17.0 98
09+09 Wall Wall — — 11.25 11.25 — — 22.50 4.90 ~ 24.40 2160 630 ~ 2420 9.6 2.8 ~ 10.7 98
09+09 Wall Duct — — 11.15 11.15 — — 22.30 5.00 ~ 23.80 2270 690 ~ 2480 10.1 3.1 ~ 11.0 98
09+09 Duct Duct — — 11.05 11.05 — — 22.10 5.10 ~ 23.20 2440 770 ~ 2610 10.8 3.4 ~ 11.6 98
09+12 Wall Wall — — 10.96 15.34 — — 26.30 4.90 ~ 28.40 2690 630 ~ 3150 11.9 2.8 ~ 14.0 98
09+12 Wall Duct — — 10.67 14.93 — — 25.60 5.00 ~ 27.70 2820 690 ~ 3230 12.5 3.1 ~ 14.3 98
09+12 Duct Wall — — 10.67 14.93 — — 25.60 5.00 ~ 27.70 2820 690 ~ 3230 12.5 3.1 ~ 14.3 98
09+12 Duct Duct — — 10.38 14.52 — — 24.90 5.10 ~ 26.40 2900 770 ~ 3200 12.9 3.4 ~ 14.2 98
09+15 Wall Wall — — 10.00 20.00 — — 30.00 7.20 ~ 32.30 3090 710 ~ 3620 13.7 3.1 ~ 16.1 98
09+15 Wall Duct — — 9.77 19.53 — — 29.30 7.30 ~ 31.60 3300 880 ~ 3900 14.6 3.9 ~ 17.3 98
09+15 Duct Wall — — 9.77 19.53 — — 29.30 7.20 ~ 31.30 3160 780 ~ 3640 14.0 3.5 ~ 16.1 98
09+15 Duct Duct — — 9.50 19.00 — — 28.50 7.30 ~ 30.60 3380 960 ~ 3940 15.0 4.3 ~ 17.5 98
09+18 Wall Wall — — 8.97 21.53 — — 30.50 7.10 ~ 32.60 3100 700 ~ 3620 13.8 3.1 ~ 16.1 98
09+18 Wall Duct — — 8.76 21.04 — — 29.80 7.30 ~ 31.80 3420 880 ~ 3970 15.2 3.9 ~ 17.6 98
09+18 Duct Wall — — 8.76 21.04 — — 29.80 7.20 ~ 31.70 3170 770 ~ 3640 14.1 3.4 ~ 16.1 98
09+18 Duct Duct — — 8.53 20.47 — — 29.00 7.30 ~ 30.80 3500 960 ~ 3970 15.5 4.3 ~ 17.7 98
12+12 Wall Wall — — 15.00 15.00 — — 30.00 6.10 ~ 30.50 3510 700 ~ 3630 15.6 3.1 ~ 16.1 98
12+12 Duct Wall — — 14.15 14.15 — — 28.30 6.20 ~ 28.30 3350 770 ~ 3350 14.9 3.4 ~ 14.9 98
12+12 Duct Duct — — 13.20 13.20 — — 26.40 6.30 ~ 26.40 3200 850 ~ 3200 14.2 3.8 ~ 14.2 98
12+15 Wall Wall — — 12.56 17.94 — — 30.50 7.20 ~ 32.30 3210 710 ~ 3620 14.2 3.1 ~ 16.1 98
12+15 Wall Duct — — 12.27 17.53 — — 29.80 7.30 ~ 31.60 3420 880 ~ 3900 15.2 3.9 ~ 17.3 98
12+15 Duct Wall — — 12.27 17.53 — — 29.80 7.20 ~ 31.30 3280 780 ~ 3640 14.6 3.5 ~ 16.1 98
12+15 Duct Duct — — 11.94 17.06 — — 29.00 7.30 ~ 30.60 3500 960 ~ 3940 15.5 4.3 ~ 17.5 98
12+18 Wall Wall — — 11.42 19.58 — — 31.00 10.00 ~ 32.60 3210 860 ~ 3620 14.2 3.8 ~ 16.1 98
12+18 Wall Duct — — 11.16 19.14 — — 30.30 10.10 ~ 31.80 3540 1060 ~ 3970 15.7 4.7 ~ 17.6 98
12+18 Duct Wall — — 11.16 19.14 — — 30.30 10.10 ~ 31.70 3280 940 ~ 3640 14.6 4.2 ~ 16.1 98
12+18 Duct Duct — — 10.87 18.63 — — 29.50 10.20 ~ 30.80 3630 1150 ~ 3970 16.1 5.1 ~ 17.7 98
15+15 Wall Wall — — 15.50 15.50 — — 31.00 9.90 ~ 33.50 2970 810 ~ 3530 13.2 3.6 ~ 15.7 98
15+15 Duct Wall — — 15.15 15.15 — — 30.30 10.00 ~ 32.70 3140 980 ~ 3720 13.9 4.3 ~ 16.5 98
15+15 Duct Duct — — 14.75 14.75 — — 29.50 10.10 ~ 31.80 3340 1160 ~ 3930 14.8 5.1 ~ 17.4 98
15+18 Wall Wall — — 14.32 17.18 — — 31.50 12.10 ~ 33.70 2990 930 ~ 3490 13.3 4.1 ~ 15.5 98
15+18 Wall Duct — — 14.00 16.80 — — 30.80 12.20 ~ 32.70 3260 1120 ~ 3720 14.5 5.0 ~ 16.5 98
15+18 Duct Wall — — 14.00 16.80 — — 30.80 12.20 ~ 32.80 3210 1110 ~ 3670 14.2 4.9 ~ 16.3 98
15+18 Duct Duct — — 13.64 16.36 — — 30.00 12.30 ~ 31.80 3450 1310 ~ 3930 15.3 5.8 ~ 17.4 98
18+18 Wall Wall — — 16.05 16.05 — — 32.10 12.10 ~ 33.80 3060 920 ~ 3450 13.6 4.1 ~ 15.3 98
18+18 Duct Wall — — 15.65 15.65 — — 31.30 12.20 ~ 32.80 3320 1110 ~ 3670 14.7 4.9 ~ 16.3 98
18+18 Duct Duct — — 15.20 15.20 — — 30.40 12.30 ~ 31.80 3570 1310 ~ 3930 15.8 5.8 ~ 17.4 98
07+07+07 Wall Wall Wall — 8.77 8.77 8.77 — 26.30 4.50 ~ 28.40 2170 550 ~ 2460 9.6 2.4 ~ 10.9 98
07+07+09 Wall Wall Wall — 8.86 8.86 11.08 — 28.80 5.80 ~ 31.10 2510 600 ~ 2920 11.1 2.7 ~ 13.0 98
07+07+09 Wall Wall Duct — 8.71 8.71 10.88 — 28.30 5.80 ~ 30.60 2590 660 ~ 3010 11.5 2.9 ~ 13.4 98
07+07+12 Wall Wall Wall — 8.08 8.08 14.14 — 30.30 7.00 ~ 32.80 2760 650 ~ 3240 12.2 2.9 ~ 14.4 98
