Dali Sound Hub User Manual

If your SOUND HUB has an HDMI
module installed, up to seven speaker
positions and one subwoofer position can
be connected, however the three DALI
wireless speaker series (OBERON C,
CALLISTOC, RUBICONC) oer some
models that are only able to assume
specific channel roles. The speakers and
roles are specified in the adjacent table.
If your SOUND HUB has no HDMI module
installed, it can connect to only stereo
le and right speaker positions and a
subwoofer. In either case the subwoofer
can be connected to the SOUND HUB
wired subwoofer output or via a DALI
WSR Wireless Subwoofer Receiver.
3. Installation and Setup
3.3 Connecting Speakers
Model Front Le Front Right Centre Side Le Side Right Rear Le Rear Right Sub
OBERON C
CALLISTOC
RUBICONC
WSR
T 1 : Speaker channel assignments
NOTE:
The way in which your SOUND HUB routes audio to a DALI WSR Wireless Subwoofer Receiver,
or to its wired subwoofer output, depends on the pe of audio material. If the material is multi-
channel encoded and input via a SOUND HUB HDMI module, the subwoofer will play the decoded
LFE (Low Frequency Eects) signal. If however the material is conventional stereo, the subwoofer
will output an appropriately low-pass filtered component of the signal. In this case, the front le
and right speaker output signals will also be appropriately high-pass filtered, depending on the
size of the speakers.
Always use the LFE input on the subwoofer when connecting the SOUND HUB or the DALI WSR.
If the subwoofer has no LFE input, connect to its standard line input and either switch its low-pass
filter to bypass or set its low-pass filter frequency to maximum.
12

Dali Sound Hub Specifications

General

Mounting type	Shelf/wall-mounted
Product color	Black
DC input voltage	4.5 V
Number of audio source inputs	-

Weight and Dimensions

Depth	213 mm
Width	300 mm
Height	76 mm
Weight	1600 g
