Dali Sound Hub User Manual

7. Installing and Using the SOUND HUB NPM BluOS Module
7.2 Network Connection
During and aer the network connection process,
the “Status” LED located on the NPM rear panel will
illuminate to indicate dierent setup states. These
are described in the following table:
LED Blink Code Description
Steady Blue Connected to WiFi and ready for use
/
Flashing Red/Green Re-starting
Solid Green WiFi network connection mode
Flashing Green Connecting to WiFi network
Steady White Indexing available network music files
Pulsing White Firmware update available
/
Alternate flashing Red/Green Firmware update in progress
Flashing Red Reset to Defaults underway
Continuous Red Error (restart the SOUND HUB)
T 2: LED Blink Codes
43

Dali Sound Hub Specifications

General

Mounting type	Shelf/wall-mounted
Product color	Black
DC input voltage	4.5 V
Number of audio source inputs	-

Weight and Dimensions

Depth	213 mm
Width	300 mm
Height	76 mm
Weight	1600 g
