Dali Sound Hub User Manual

USB
Service
Status
ServiceUSBLAN
7. Installing and Using the SOUND HUB NPM BluOS Module
The NPM modules employ the BluOS streaming
platform to enable the SOUND HUB to connect
to a home WiFi or Ethernet network and play
audio from a wide range of music streaming
services, network music libraries, internet radio
stations and USB storage. The NPM-2i module
diers from the NPM-1 module by incorporating
Apple Airplay 2 streaming technology.
7.1 Installation
The NPM module pack includes the following
items:
• NPM module
• USB WiFi Dongle
• USB extension cable
To install an NPM module in your SOUND HUB
follow the steps on the following page.
NOTE:
If an NPM module is to be removed, the SOUND
HUB power supply must first be disconnected.
39

Dali Sound Hub Specifications

General

Mounting type	Shelf/wall-mounted
Product color	Black
DC input voltage	4.5 V
Number of audio source inputs	-

Weight and Dimensions

Depth	213 mm
Width	300 mm
Height	76 mm
Weight	1600 g
