NOTE:
SOUND HUB without
HDMI module.
The SOUND HUB must be switched ON.
D 7: Connecting Speakers
3. Installation and Setup
3.3 Connecting Speakers
Press the LINK & CONNECT buon on
the SOUND HUB.
Press the LINK & CONNECT buon on
the SOUND HUB.
HUB
HUB
L
L
R
R
5-10
sec.
Press the LINK & CONNECT buon on
the LEFT speaker.
Press the LINK & CONNECT buon
repeatedly to select the required
channel.
HUB
L R
5-10
sec.
Press the LINK & CONNECT buon on
the RIGHT speaker.
Press the LINK & CONNECT buon
repeatedly to select the required
channel.
HUB
L R
5-10
sec.
A
B
C
D
E
F
14
