Dali Sound Hub User Manual

AUX IN
RCA IN
OPTICAL IN OPTICAL IN USB POWER/
SERVICE
COAXIAL
PRE OUT
POWER
15V 2.8A
L R L R
Input
Output
SUB OUT
PLUG-IN MODULE
PLUG-IN MODULE
AUX IN
RCA IN
OPTICAL IN OPTICAL IN USB POWER/
SERVICE
COAXIAL
PRE OUT
POWER
15V 2.8A
L R L R
Input
Output
SUB OUT
PLUG-IN MODULE
PLUG-IN MODULE
6. Trouble-Shooting and Maintaining Your SOUND HUB
6.4 Firmware Update
DALI may occasionally release updated firmware for your SOUND HUB.
Updated firmware may improve performance and reliabili or introduce
new features. Firmware updates will be made available for download from
the DALI website. To install a firmware update follow the steps below.
• Download the firmware file from the DALI website (see link below).
• Transfer the firmware file to an emp USB memory stick using the
dedicated DALI tool available for Windows and macOS.
• Disconnect the SOUND HUB from its power supply.
• Insert the USB memory stick into the “USB Power/Service” socket on
the SOUND HUB rear panel.
• Reconnect the SOUND HUB power supply and wait for the small
indicator next to the USB Power/Service socket to blink green.
• Remove the USB memory stick from the SOUND HUB.
• The SOUND HUB firmware will now be updated.
www.dali-speakers.com/firmware
36

Dali Sound Hub Specifications

General

Mounting type	Shelf/wall-mounted
Product color	Black
DC input voltage	4.5 V
Number of audio source inputs	-

Weight and Dimensions

Depth	213 mm
Width	300 mm
Height	76 mm
Weight	1600 g
