Dali Sound Hub User Manual

10. Diagrams / Tables
Diagrams
D 1: SOUND HUB Rear Panel 5
D 2: SOUND HUB Front Panel 6
D 3: Remote Control 7
D 4: Setups 8
D 5: In the box 9
D 6: Inserting baeries 11
D 7: Connecting Speakers 14
D 8: Multi-Channel Home Theatre System 15
D 9: NPM-2i module rear panel 41
D 10: HDMI module rear panel 47
D 11: HDMI module 50
D 12: HDMI module switches 52
Tables
T 1 : Speaker channel assignments 12
T 2: LED Blink Codes 43
T 3: Valid Multi-Channel Speaker Arrangements 56
59

Dali Sound Hub Specifications

General

Mounting type	Shelf/wall-mounted
Product color	Black
DC input voltage	4.5 V
Number of audio source inputs	-

Weight and Dimensions

Depth	213 mm
Width	300 mm
Height	76 mm
Weight	1600 g
