Dali Sound Hub User Manual

3. Installation and Setup
3.3 Connecting Speakers
D 8: Multi-Channel Home Theatre System
The SOUND HUB must be switched ON.
Press the LINK & CONNECT
buon on the SOUND HUB.
Press the LINK & CONNECT
buon on the SOUND HUB.
5-10
sec.
Press the LINK & CONNECT
buon on the first speaker.
Repeat procedure for each speaker.
Press the LINK & CONNECT buon
repeatedly if necessary to select the
required channel.
5-10
sec.
NOTE:
System with SOUND HUB
including HDMI module.
A
B
C
D
F
15

Dali Sound Hub Specifications

General

Mounting type	Shelf/wall-mounted
Product color	Black
DC input voltage	4.5 V
Number of audio source inputs	-

Weight and Dimensions

Depth	213 mm
Width	300 mm
Height	76 mm
Weight	1600 g
