Dali Sound Hub User Manual

C
E
D
NOTE:
The default order of Speaker
Balance Adjustment is: Centre,
Front Right, Side Right, Rear
Right, Rear Le, Side Le, Front
Le, Subwoofer. Uninstalled
speaker positions will be omied.
If multiple speakers are installed
at a single channel position, they
will be available for adjustment
independently in the order which
they were originally connected.
NOTE:
Your SOUND HUB will automatically
return to normal operation without
saving speaker balance adjustments
if no action is taken for two minutes.
• Press the front panel Source Select buon
C
to move to the next speaker, or press the Mute
buon
D
to return to the previous speaker,
and adjust the balance. If no adjustment is
required for a speaker, press the Source
Select buon again to move on to the next one.
• When all the required speaker or subwoofer
adjustments are made, press and hold the
Source Select buon
E
to save and exit from
Speaker Balance Adjustment. If you wish to exit
Speaker Balance Adjustment without saving
any changes, press and hold the front panel
Standby buon.
Once initial volume balance has been achieved
you may find it beneficial to revisit the adjustment
routine as you become more familiar with the
performance of your system. This is especially
likely with the multi-channel systems made
possible by the SOUND HUB HDMI module.
5. Using Your SOUND HUB
5.7 Speaker Balance Adjustment
28

Dali Sound Hub Specifications

General

Mounting type	Shelf/wall-mounted
Product color	Black
DC input voltage	4.5 V
Number of audio source inputs	-

Weight and Dimensions

Depth	213 mm
Width	300 mm
Height	76 mm
Weight	1600 g
