Dali Sound Hub User Manual

8. Installing and Using the SOUND HUB HDMI Module
8.2 Configuring Your HDMI Equipped SOUND HUB
In addition to Speaker Balance Adjustment
(see Section5.8 / page29) and Speaker
Distance Adjustment (see Section5.8 /
page29), two further HDMI module options
that are particularly relevant for multi-channel
systems can be configured by switches on the
HDMI module. The switches are illustrated in
DiagramD 12 / page52, and their options are
described in the following paragraphs.
Upmix HDMI To All Speakers
The “Upmix HDMI To All Speakers” switch
configures how an HDMI module equipped
SOUND HUB treats programme material
encoded with fewer channels than there are
speakers connected. Example: The programme
material playing via the HDMI module is stereo
(2.0), yet the SOUND HUB has five speakers and
a subwoofer connected (5.1).
If the “Upmix HDMI To All Speakers” switch is set to YES, audio
material will be routed appropriately to and played by all the
connected speakers. The SOUND HUB will intelligently decide on
the appropriate signal routed to each speaker.
NOTE:
Regardless of the HDMI upmix option selected, when either a
wired or wireless subwoofer is connected, SOUND HUB bass
management will automatically ensure that the appropriate
signal is routed to the subwoofer – taking into account both
audio formats and connected DALI speaker models.
51

Dali Sound Hub Specifications

General

Mounting type	Shelf/wall-mounted
Product color	Black
DC input voltage	4.5 V
Number of audio source inputs	-

Weight and Dimensions

Depth	213 mm
Width	300 mm
Height	76 mm
Weight	1600 g
