Installation and User Guide DEVIreg™ Multi
FEC | Produced by Danfoss ©28
Additionally, DEVIreg™ Multi controller can be set up with status OFF by ‘mechanical’
switch connected to DI8:
Alarm
NC 8
DI 8
C 8
NO 8
COM
DI 5-8
OFF ON
Dev ice
NB: When no switch is used – it means Device is always ON.
When Device is OFF by 'mechanical' switch two hash sign/symbols – ‘##’ – are visible in
the left corner of Main Screen, for example:
