Danfoss DSH Series Application Guide

Dilution Chart - DSH090 to DSH184 R410A
Figure 54: Dilution Chart (reference at 20°C / 68°F ambient temperature)
22.5
25
20
17.5
15
12.5
10
7.5
5
-25-30 -20 -15 -10 -5 0 5 10 15 20 25
-13-22 -4 5 14 23 32 41 50 59 68 77
2.5
0
40.5
45
36
31.5
27
22.5
18
13.5
9
4.5
0
Unsafe Area (60 sec max per hour)
Safe Area
Evaporating Temperature (°C)
Evaporating Temperature (°F)
Oil Superheat (K)
Oil Superheat (°F)
CC-000024
Dilution Chart - DSH090 to DSH184 R452B / R454B
Figure 55: Dilution Chart (reference at 20°C / 68°F ambient temperature)
22.5
25
20
17.5
15
12.5
10
7.5
5
-25-30 -20 -15 -10 -5 0 5 10 15 20 25
-13-22 -4 5 14 23 32 41 50 59 68 77
2.5
0
40.5
45
36
31.5
27
22.5
18
13.5
9
4.5
0
Unsafe Area (60 sec max per hour)
Safe Area
Evaporating Temperature (°C)
Evaporating Temperature (°F)
Oil Superheat (K)
Oil Superheat (°F)
CC-000025
Scroll compressors, DSH090 to DSH600 | Application
© Danfoss | Climate Solutions | 2022.10 AB288965961751en-001402 | 50
