Danfoss DSH Series Application Guide

Compressor model
Connections
Motor protection
Code no.
3
4
7
9
208-230/3/60
380-415/3/50
460/3/60
575/3/60
380-400/3/60
DSH485
Brazed
Module 110-240V
(1)
120H1738
120H1361
-
120H1715
DSH600
Brazed
Module 24V AC
(1)
-
120H1789
-
120H1780
DSH600
Brazed
Module 110-240V
(1)
-
120H1785
-
120H1782
(1)
Electronic motor protection, module located in terminal box
(1)
Electronic motor protection, module located in terminal box
Compressors compatible R410A only
Table 44: Industrial pack compressors compatible R410A only
Compressor model
Connections
Motor protection
Code no.
3
4
7
9
208-230/3/60
380-415/3/50
460/3/60
575/3/60
380-400/3/60
DSH090
Brazed
Internal
120H1508
-
120H1514
120H1516
DSH105
Brazed
Internal
120H1518
-
120H1524
120H1526
DSH120
Brazed
Internal
120H1528
-
120H1534
120H1536
DSH140
Brazed
Internal
120H1538
-
120H1544
120H1546
DSH161
Brazed
Internal
120H1548
-
120H1554
120H1556
DSH184
Brazed
Internal
120H1558
-
120H1564
120H1566
DSH240
Brazed
Module 24V AC
(1)
120H1290
120H1330
-
120H1314
DSH240
Brazed
Module 110-240V
(1)
120H1288
120H1328
-
120H1312
DSH295
Brazed
Module 24V AC
(1)
120H1286
120H1326
-
120H1310
DSH295
Brazed
Module 110-240V
(1)
120H1284
120H1324
-
120H1308
(1)
Electronic motor protection, module located in terminal box
(1)
Electronic motor protection, module located in terminal box
© Danfoss | Climate Solutions | 2022.10 AB288965961751en-001402 | 67
Scroll compressors, DSH090 to DSH600 | Ordering
