FC 300 Instruction Manual
General Specifications
Control characteristics:
Resolution of output frequency at 0 - 1000 Hz ........................................................................ 0.013 Hz
Repeat accuracy of Precise start/stop (terminals 18, 19) ............ FC 301: ≤ ±1ms/FC302:≤ ±0.1msec
System response time (terminals 18, 19, 27, 29, 32, 33) ................... FC 301: ≤ 10 ms / FC 302: ≤ 2ms
Speed control range (open loop) ............................................................... 1:100 of synchronous speed
Speed control range (closed loop) ............................................................ 1:1000 of synchronous speed
Speed accuracy (open loop) ......................................................... 30 - 4000 rpm: Max. error of ±8 rpm
Speed accuracy (closed loop) .................................................... 0 - 6000 rpm: Max. error of ±0.15 rpm
All control characteristics are based on a 4-pole asynchronous motor
Surroundings:
Enclosure ≤ 10 HP [7.5 kW] ............................................................................................ IP 20, IP 55
Enclosure ≥ 14.75 HP [11 kW] ......................................................................................... IP 21, IP 55
Enclosure kit available ≤ 10 HP [7.5 kW] ............................................................ IP21/TYPE 1/IP 4X top
Vibration test ............................................................................................................ 0.03 oz [1.0 g]
Max. relative humidity ................. 5% - 95% (IEC 721-3-3 ); Class 3K3 (non-condensing) during operation
Aggressive environment (IEC 721-3-3), uncoated ................................................................. class 3C2
Aggressive environment (IEC 721-3-3), coated .................................................................... class 3C3
Ambient temperature ............................... Max. 122°F [50°C] (24-hour average maxi mum 113°F [45°C])
Derating for h igh ambient temperature, see special conditions in the Design Guide
Minimum a mbient temperature during full-scale operation ................................................... 32°F [0°C]
Minimum a mbient temperature at reduced performance ................................................... 14°F [-10°C]
Temperature during storage/transport .......................................... -13° - +149/158°F [-25° - +65/70°C]
Maximum altitude above sea level ........................................................................... 3281 ft. [1000 m ]
Derating for high altitude, see special conditions in the Design Guide.
EMC standards, Emission ........................................................ EN 61800-3, EN 61000-6-3/4, EN 55011
EMC standards, Immunity ..................................................................... EN 61800-3, EN 61000-6-1/2,
EN 61000-4-2, EN 61000-4-3 , EN 61000-4-4, EN 6100 0-4-5, EN 61000-4-6
See section on special conditions in the Design Guide
Protection and Features:
• Electronic thermal motor protection against overload.
• Temperature monitoring of the heatsink ensures that the adjustable frequency drive trips if the
temperature reaches 203°F ± 9°F [95 °C ± 5°C]. An overload temperature cannot be reset
until the temperature of the heatsink is below 158°C ± 9°C [70°C ± 5°C] ( Guide line - these
temperatures may vary for diffe rent power sizes, enclosures, etc.).
• The adjustable frequency drive is protected against short circuits on motor terminals U, V, W.
• If a line phase is missing, the adjustable frequency drive trips or issues a warning (depending on the load).
• Monitoring of the intermediate circuit voltage ensures that the adjustable frequency driv
e
trips if the interm ediate circ uit voltage is too low or too high.
• The adjustable frequency drive is protected against ground faults on motor terminals U, V, W.
57
MG.33.A6.22 - VLT is a registered Danfoss trademark
