LCP and typical control card power consumptions are included. Further options and customer load may add up to 30W to the losses.
(Though typical only 4W extra for a fully loaded control card, or options for slot A or slot B, each).
Although measurements are made with state of the art equipment, some measurement inaccuracy must be allowed for (
±
5%).
5) The three values for the max. cable cross section are for single core, flexible wire and flexible wire with sleeve, respectively.
PK75 P1K1 P1K5 P2K2 P3K0 P4K0 P5K5 P7K5
Typical Shaft Output [kW] 0.75 1.1 1.5 2.2 3 4 5.5 7.5
Enclosure IP20, IP21 A3 A3 A3 A3 A3 A3 A3 A3
Enclosure IP55 A5 A5 A5 A5 A5 A5 A5 A5
Output current
Continuous (3x525-550 V) [A] 1.8 2.6 2.9 4.1 5.2 6.4 9.5 11.5
Intermittent (3x525-550 V) [A] 2.9 4.2 4.6 6.6 8.3 10.2 15.2 18.4
Continuous (3x551-600 V) [A] 1.7 2.4 2.7 3.9 4.9 6.1 9.0 11.0
Intermittent (3x551-600 V) [A] 2.7 3.8 4.3 6.2 7.8 9.8 14.4 17.6
Continuous kVA (525 V AC) [kVA] 1.7 2.5 2.8 3.9 5.0 6.1 9.0 11.0
Continuous kVA (575 V AC) [kVA] 1.7 2.4 2.7 3.9 4.9 6.1 9.0 11.0
Max. input current
Continuous (3x525-600 V) [A] 1.7 2.4 2.7 4.1 5.2 5.8 8.6 10.4
Intermittent (3x525-600 V) [A] 2.7 3.8 4.3 6.6 8.3 9.3 13.8 16.6
Additional specifications
IP20, IP21 max. cable cross section
5)
(mains,
motor, brake and load sharing) [mm
2
(AWG)]
2)
4,4,4 (12,12,12)
(min. 0.2 (24))
IP55, IP66 max. cable cross section
5)
(mains,
motor, brake and load sharing) [mm
2
(AWG)]
4,4,4 (12,12,12)
Max. cable cross section
5)
with disconnect
6,4,4 (10,12,12)
Estimated power loss
at rated max. load [W]
4)
35 50 65 92 122 145 195 261
Weight, Enclosure IP20 [kg] 6.5 6.5 6.5 6.5 6.5 6.5 6.6 6.6
Weight, enclosure IP55 [kg] 13.5 13.5 13.5 13.5 13.5 13.5 14.2 14.2
Efficiency
4)
0.97 0.97 0.97 0.97 0.97 0.97 0.97 0.97
Table 10.7 Mains Supply 3x525-600 V AC (FC 302 only)
Specifications
VLT
®
AutomationDrive Operating
Instructions
70 MG33AM02 - VLT
®
is a registered Danfoss trademark
10
10
