P11K P15K P18K P22K P30K
High/Normal Load
1)
HO NO HO NO HO NO HO NO HO NO
Typical Shaft Output [kW] 11 15 15 18.5 18.5 22 22 30 30 37
Enclosure IP21, IP55, IP66 B1 B1 B2 B2 C1
Enclosure IP20 B3 B3 B4 B4 B4
Output current
Continuous (3x525-550 V) [A] 19 23 23 28 28 36 36 43 43 54
Intermittent (3x525-550 V) [A] 30 25 37 31 45 40 58 47 65 59
Continuous (3x525-600 V) [A] 18 22 22 27 27 34 34 41 41 52
Intermittent (3x525-600 V) [A] 29 24 35 30 43 37 54 45 62 57
Continuous kVA (550 V AC) [kVA] 18.1 21.9 21.9 26.7 26.7 34.3 34.3 41.0 41.0 51.4
Continuous kVA (575 V AC) [kVA] 17.9 21.9 21.9 26.9 26.9 33.9 33.9 40.8 40.8 51.8
Max. input current
Continuous at 550 V [A] 17.2 20.9 20.9 25.4 25.4 32.7 32.7 39 39 49
Intermittent at 550 V [A] 28 23 33 28 41 36 52 43 59 54
Continuous at 575 V [A] 16 20 20 24 24 31 31 37 37 47
Intermittent at 575 V [A] 26 22 32 27 39 34 50 41 56 52
Additional specifications
IP21, IP55, IP66 max. cable cross-
section
5)
(mains, brake, load sharing)
[mm
2
(AWG)]
2)
16, 10, 10 (6, 8, 8) 16, 10, 10 (6, 8, 8) 35,-,-(2,-,-) 35,-,-(2,-,-) 50,-,- (1,-,-)
IP21, IP55, IP66 max. cable cross-
section
5)
(motor) [mm
2
(AWG)]
2)
10, 10,- (8, 8,-) 10, 10,- (8, 8,-) 35, 25, 25 (2, 4, 4) 35, 25, 25 (2, 4, 4) 50,-,- (1,-,-)
IP20 max. cable cross-section
5)
(mains, brake, motor and load
sharing)
10, 10,- (8, 8,-) 10, 10,- (8, 8,-) 35,-,-(2,-,-) 35,-,-(2,-,-) 35,-,-(2,-,-)
Max. cable cross-section with
Disconnect [mm
2
(AWG)]
2)
16, 10, 10
(6, 8, 8)
50, 35, 35
(1,2, 2)
Estimated power loss
at rated max. load [W]
4)
225 285 329 700 700
Weight, enclosure IP21, [kg] 23 23 27 27 27
Weight, enclosure IP20 [kg] 12 12 23.5 23.5 23.5
Efficiency
4)
0.98 0.98 0.98 0.98 0.98
Table 10.8 Mains Supply 3x525-600 V AC (FC 302 only)
