Danfoss FC 300 User Manual

P37K P45K P55K P75K
High/Normal Load
1)
HO NO HO NO HO NO HO NO
Typical Shaft Output [kW] 37 45 45 55 55 75 75 90
Enclosure IP21, IP55, IP66 C1 C1 C1 C2 C2
Enclosure IP20 C3 C3 C3 C4 C4
Output current
Continuous (3x525-550 V) [A] 54 65 65 87 87 105 105 137
Intermittent (3x525-550 V) [A] 81 72 98 96 131 116 158 151
Continuous (3x525-600 V) [A] 52 62 62 83 83 100 100 131
Intermittent (3x525-600 V) [A] 78 68 93 91 125 110 150 144
Continuous kVA (550 V AC) [kVA] 51.4 61.9 61.9 82.9 82.9 100.0 100.0 130.5
Continuous kVA (575 V AC) [kVA] 51.8 61.7 61.7 82.7 82.7 99.6 99.6 130.5
Max. input current
Continuous at 550 V [A] 49 59 59 78.9 78.9 95.3 95.3 124.3
Intermittent at 550 V [A] 74 65 89 87 118 105 143 137
Continuous at 575 V [A] 47 56 56 75 75 91 91 119
Intermittent at 575 V [A] 70 62 85 83 113 100 137 131
Additional specifications
IP20 max. cable cross-section
5)
(mains and
motor)
50 (1) 150 (300 MCM)
IP20 max. cable cross-section
5)
(brake and
load sharing)
50 (1) 95 (4/0)
IP21, IP55, IP66 max. cable cross-section
5)
(mains, motor) [mm
2
(AWG)]
2)
50 (1) 150 (300 MCM)
IP21, IP55, IP66 max. cable cross-section
5)
(brake, load sharing) [mm
2
(AWG)]
2)
50 (1) 95 (4/0)
Max cable size with mains disconnect
[mm
2
(AWG)]
2)
50, 35, 35
(1, 2, 2)
95, 70, 70
(3/0, 2/0, 2/0)
185, 150, 120
(350MCM, 300MCM,
4/0)
Estimated power loss at rated max. load
[W]
4)
850 1100 1400 1500
Weight, enclosure IP20 [kg] 35 35 50 50
Weight, enclosure IP21, IP55 [kg] 45 45 65 65
Efficiency
4)
0.98 0.98 0.98 0.98
Table 10.9 Mains Supply 3x525-600 V AC (FC 302 only)
Specifications
VLT
®
AutomationDrive Operating
Instructions
72 MG33AM02 - VLT
®
is a registered Danfoss trademark
10
10

Danfoss FC 300 Specifications

General

Enclosure	IP20
Approvals	cUL, UL, CE
EMC filter	Built-in
Communication Options	CANopen, PROFIBUS DP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Output Voltage	0-100% of supply voltage
