Danfoss H1 Series User Manual

Axial and radial ports dimensions, mm [in]
Measure
Size 060 Size 080 Size 110 Size 160 Size 210
AA
247.8 [9.76] 265.9 [10.47] 283.9 [11.18] 311.7 [12.27]
336.6 [13.25]
AB
164.7 [6.48] 170.6 [6.72] 175.0 [6.89] 183.8 [7.24]
190.9 [7.52]
AC
167.5 [6.59] 179.9 [7.08] 196.9 [7.75] 219.7 [8.65]
232.6 [9.16]
BA
180.3 [7.10] 194.8 [7.67] 207.8 [8.18] 232.0 [9.13]
256.1 [10.08]
BB
32.3 [1.27] 34.7 [1.37] 37.5 [1.49] 42.0 [1.65]
46.4 [1.83]
BC
74.4 [2.93] 78.4 [3.09] 88.9 [3.50] 99.9 [3.93]
108.2 [4.26]
BD
165.5 [6.56] 179.9 [7.08] 194.4 [7.65] 216.0 [8.50]
236.3 [9.3]
BE
84.0 [3.30] 92.4 [3.64] 102.5 [4.04] 115.4 [4.54]
123.5 [4.86]
BH
180.3 [7.10] 194.8 [7.67] 207.8 [8.18] 232.0 [9.13]
256.1 [10.08]
BJ
32.3 [1.27] 34.7 [1.37] 37.5 [1.48] 42.0 [1.65]
46.4 [1.83]
BK
69.5 [2.74] 75.2 [2.96] 85.0 [3.35] 96.0 [3.78]
104.3 [4.11]
BL
50.8 [2.00] 57.2 [2.25] 57.2 [2.25] 66.6 [2.62]
66.6 [2.62]
BM
23.8 [0.94] 27.8 [1.09] 27.8 [1.09] 31.8 [1.25]
31.8 [1.25]
CA
219.2 [8.63] 234.7 [9.24] 250.1 [9.84] 275.0 [10.83]
295.9 [11.65]
CB
43.4 [1.71] 46.2 [1.82] 49.6 [1.95] 54.4 [2.14]
57.8 [2.28]
CC
48.0 [1.89] 50.0 [1.97] 50.0 [1.97] 60.0 [2.36]
65 [2.56]
CD
50.8 [2.00] 57.2 [2.25] 57.2 [2.25] 66.6 [2.62]
66.6 [2.62]
CE
23.8 [0.94] 27.8 [1.09] 27.8 [1.09] 31.8 [1.25]
31.8 [1.25]
CF
45.0 [1.77] 46.0 [1.81] 63.0 [2.48] 54.5 [2.15]
66.9 [2.63]
CG
85.8 [3.38] 90.0 [3.54] 96.0 [3.78] 102.2 [4.02]
108.5 [4.27]
CH
18.0 [0.71] 22.0 [0.87] 21.0 [0.83] 23.0 [0.91]
25 [0.98]
CJ
68.0 [2.68] 80.0 [3.15] 87.0 [3.43] 90.9 [3.58]
104.3 [4.11]
CK
70.0 [2.76] 75.0 [2.95] 83.0 [3.27] 96.5 [3.80]
103.5 [4.07]
CL
58.9 [2.32] 65.3 [2.57] 68.8 [2.71] 75.8 [2.98]
84.9 [3.34]
CM
89.3 [3.52] 93.7 [3.69] 97.2 [3.83] 105.6 [4.16]
111.2 [4.38]
CN
220.3 [8.67] 234.7 [9.24] 251.1 [9.89] 276.0 [10.87]
296.9 [11.69]
CO
43.7 [1.72] 46.2 [1.82] 49.9 [1.96] 54.6 [2.15]
58.1 [2.29]
CP
48.0 [1.89] 50.0 [1.97] 50.0 [1.97] 60.0 [2.36]
65 [2.56]
α
17° 17° 19° 17° 17°
For further detailed information about DIN ports dimensions see the DIN flange design ports per ISO 11
926-1 on page 106.
Legend:
1 Loop flushing relief valve
2 Loop flushing shuttle spool
3 Speed sensor
4 Minimum angle stop adjustment
5 Connector: DT04-2P
6 Alternate position of case drain port
Technical Information
H1 Bent Axis Variable Displacement Motors, Size 060/080/110/160/210/250
Dimensions
©
Danfoss | December 2016 11037153 | BC00000043en-US1103 | 101
