Axial and radial ports dimensions, mm [in]
Measure Size 060 Size 080 Size 110 Size 160
AA
158.9 [6.26] 159.0 [6.26] 173.5 [6.83] 200.6 [7.90]
AB
114.7 [4.52] 119.4 [4.70] 130.8 [5.15] 138.2 [5.44]
AC
193.6 [7.62] 206.6 [8.13] 224.1 [8.82] 242.5 [9.55]
AD
112.7 [4.44] 112.7 [4.44] 112.7 [4.44] 112.7 [4.44]
AE
67.3 [2.65] max 67.3 [2.65] max 67.3 [2.65] max 67.3 [2.65] max
AF
161.1 [6.34] 161.1 [6.34] 175.9 [6.93] 200.6 [7.90]
BA
120.9 [4.76] 116.7 [4.59] 125.8 [4.95] 149.6 [5.89]
BB
32.3 [1.27] 34.7 [1.38] 37.5 [1.48] 42.0 [1.65]
BC
74.4 [2.93] 78.4 [3.09] 88.9 [3.50] 99.9 [3.93]
BD
105.6 [4.16] 95.6 [3.76] 105.5 [4.15] 129.7 [5.11]
BE
83.8 [3.30] 90.6 [3.54] 100.9 [3.97] 111.7 [4.40]
BF
29.0 [1.14] 20.0 [0.79] 31.0 [1.22] 50.0 [1.97]
BH
120.9 [4.76] 116.4 [4.58] 125.8 [4.95] 149.6 [5.89]
BJ
32.3 [1.27] 34.7 [1.37] 37.5 [1.48] 42.0 [1.65]
BK
69.5 [2.74] 75.2 [2.96] 85.0 [3.35] 96.0 [3.78]
BL
50.8 [2.0] 57.2 [2.25] 57.2 [2.25] 66.6 [2.62]
BM
23.8 [0.94] 27.8 [1.09] 27.8 [1.09] 31.8 [1.25]
CA
149.6 [5.89] 147.8 [5.82] 162.3 [6.39] 184.6 [7.27]
CB
40.6 [1.6] 43.7 [1.72] 48.0 [1.89] 52.1 [2.05]
CC
48.0 [1.89] 50.0 [1.97] 50.0 [1.97] 60.0 [2.36]
CD
50.8 [2.0] 57.2 [2.25] 57.2 [2.25] 66.6 [2.62]
CE
23.8 [0.94] 27.8 [1.09] 27.8 [1.09] 31.8 [1.25]
CF
32.2 [1.27] 31.0 [1.22] 34.1 [1.34] 51.8 [2.04]
CG
44.0 [1.73] 56.8 [2.24] 55.0 [2.17] 50.0 [1.97]
CH
75.0 [2.95] 78.0 [3.07] 86.0 [3.39] 97.0 [3.82]
CJ
44.2 [1.74] 36.0 [1.42] 38.1 [1.50] 52.8 [2.09]
CK
35.0 [1.38] 46.0 [1.81] 47.9 [1.89] 51.0 [2.01]
CL
26.1 [1.03] 21.5 [0.85] 22.9 [0.9] 25.1 [0.99]
CM
74.8 [2.94] 74.4 [2.93] 79.0 [3.11] 87.7 [3.45]
CN
149.9 [5.9] 148.2 [5.83] 163.3 [6.43] 184.6 [7.27]
CO
40.7 [1.60] 43.8 [1.72 48.2 [1.90] 52.3 [2.06]
CP
48.0 [1.89] 50.0 [1.97] 50.0 [1.97] 60.0 [2.36]
CR
68.4 [2.69] 68.2 [2.69] 70.4 [2.77] 30.0 [1.18]
α
25°
For further details see the Cartridge flange design ports per ISO 11 926-1 on page 116.
Legend:
1 Loop flushing relief valve
2 Loop flushing shuttle spool
3 Speed sensor
4 Minimum angle stop adjustment
5 Connector: DT04-2P
6 Alternate position of case drain port
Technical Information
H1 Bent Axis Variable Displacement Motors, Size 060/080/110/160/210/250
Dimensions
©
Danfoss | December 2016 11037153 | BC00000043en-US1103 | 115
