Frame size 060 and 080 shaft options
ØA
ØJ
ØD
ØH
ØG
ØC
ØB
DC
DG
DH
DJ
DF
DD
DB
DA
P003 449
(2x)
(2x)
DN
DK
DL DL
DM
R
DE
V
23
31
8
V (M10)
∅14.9 ∅10.5
M10x1.5
29
38
10
V (M12)
∅18.1 ∅13
M12x1.75
38
44
12.5
V (M16)
∅23 ∅17
M16x2
1
2
1. Coupling must not protrude beyong this surface
2. Maximum screw head space other side
Shaft dimensions for frame sizes 060 and 080, mm [in]
Option AN/AS BN/BS CN/CS GN/GS HN/HS JN/JS
Teeth 14 21 23 14 16 18
Pitch-Ø
29.633
[1.167]
33.337
[1.312]
36.513
[1.438]
28.0 [1.102] 32.0 [1.260] 36.0 [1.417]
Spline
*
ANSI B92.1-1970 Class 5 flat root side fit W30x2x30x14x9g W35x2x30x16x9g W40x2x30x18x9g
A
34.4 [1.315] 34.4 [1.315] 37.6 [1.48] 29.6 [1.165] 34.6 [1.362] 39.6 [1.559]
ØH
44.5 [1.752] 44.5 [1.752] 44.5 [1.752] 44.5 [1.752] 44.5 [1.752] 44.5 [1.752]
ØJ
25.8 [1.016] 30.0 [1.181] 32.0 [1.260] 25.0 [0.984] 30.0 [1.181] 35.0 [1.378]
DA
37.5 [1.476] 37.5 [1.476] 37.5 [1.476] 27.0 [1.063] 32.0 [1.260] 37.0 [1.457]
DB
47.5 [1.87] 47.5 [1.87] 47.5 [1.87] 35.0 [1.378] 40.0 [1.575] 45.0 [1.772]
DC (060) 139.7 [5.500] 139.7 [5.500] —
127.2 [5.008]
132.2 [5.205]
—
DC (080) 157.9 [6.217] 157.9 [6.217] 157.9 [6.217]
—
150.4 [5.921]
155.4 [6.118]
R
3.0 [0.118] 3.0 [0.118] 3.0 [0.118] 1.6 [0.063] 1.6 [0.063] 1.6 [0.063]
V
M10 M10 M12 M10 M10 M12
Angle
Pressure angle 30°
*
Spline per DIN 5480, side fit.
Shaft options overview for frame sizes 060 and 080
Size Shaft option
AN/AS BN/BS CN/CS GN/GS HN/HS JN/JS
060
— —
080
—
= available option; — = not available option
Technical Information
H1 Bent Axis Variable Displacement Motors, Size 060/080/110/160/210/250
Dimensions
118 |
©
Danfoss | December 2016 11037153 | BC00000043en-US1103
