S – Charge pump
F
14 cm³/rev [0.85 in³/rev]
C
17 cm³/rev [1.03 in³/rev]
N
No charge pump, external charge supply (Align with options: E and T)
T – Filtration (Align with option G: Endcap selection)
L
Suction filtration (see H1P 069/078, suction filtration, option L on page 64)
M
Integral full charge flow filtration with bypass, bypass sensor, medium filter length, 11004918
N
Integral full charge flow filtration with bypass, bypass sensor (no filter)
P
Remote full charge flow filtration
E
External charge flow filtration (Align with options: N and S)
V – Charge pressure relief setting
20
20 bar [290 psi]
22
22 bar [319 psi]
24
24 bar [348 psi]
26
26 bar [377 psi]
28
28 bar [406 psi]
30
30 bar [435 psi]
32
32 bar [464 psi]
34
34 bar [493 psi]
W – Special hardware features
PN
EDC / FNR / MDC valve plate
P1
NFPE valve plate (Align with options: D and E)
P2
NFPE / FDC / AC valve plate and speed ring on the cylinder block
P4
EDC / FNR / MDC valve plate with speed ring on the cylinder block (Align with options: D and E )
H1
MDC / EDC / FNR valve plate with MDC handle
X – Paint and nametag
NNN
Black paint and Danfoss nametag
Technical Information H1 Axial Piston Single Pumps, Size 069/078
Master model code H1P 069/078
