Danfoss H1 Technical Information

Automotive controls with MOR: AC I – options A7 (12V) / C2 (24V) and AC II – options B7 (12V) / C3 (24V)
61.2 ±0.8 61.2 ±0.8
30.2 ±0.8
208.9
±
2.5
190.5
±
1.2
2x 187.1 ±
1.2
C1
CAN
CC2
CC2
C2
V
209 max
89.2 ±0.8
V
P005 930
4
3
1
2
CAN
CC1
CC2
CCC3
1. Mounting flange
2. Shaft
3. Plug removing can cause contamination issues
4. “PPU” wire harness is factory installed to speed sensor
Connector description
Port Description Note
C1
C2
Control MOR Depressing the plunger mechanically moves the control spool.
Actuation allows full stroke pump response as per coil and
rotation dependent control logic.
CC1
Control connector Deutsch DTM04-12P -A-
Paint free
CC2
Control connector Deutsch DTM04-12P -B-
CCC3
Control connector Deutsch DT06-2S
For using connector the plug may be removed.
Paint free
CAN
Control connector Deutsch DTM04-3P
Please contact Danfoss Power Solutions representative for specific installation drawings.
Technical Information
H1 Axial Piston Single Pumps, Size 069/078
Controls
62 11062169 • Rev 0700 • November 2015
