99.7 ±1.0
[3.93 ±0.04]
154.2 ±1.0
[6.07 ±0.04]
139.3 ±1.0
[5.48 ±0.04]
45.2 ±1.0
[1.78 ±0.04]
95.0 ±2.0
[3.74 ±0.079]
104.0 ±1.0
[4.09 ±0.04]
23.7
[0.93]
96.5 ±1.0
[3.80 ±0.04]
96.6 ±1.0
[3.78 ±0.04]
126.1 ±1.0
[4.96 ±0.04]
152.9 ±1.0
[6.02 ±0.04]
178.9 ±2.0
[7.04 ±0.079]
88.0 ±0.2
[3.46 ±0.01]
138.18 ±2
[5.44 ±0.079]
108.9 ±2
[4.29 ±0.079]
1.37
[0.054]
142.7
[5.62]
Approximate center
of gravity
Approximate center
of gravity
W
Y
X
12°
12°
E-E
F-F
G-G
G
G
Shaft L
c
Connector :
Deutsch DT04-2P
to be paint free
P003 327E
Z
Charge pressure construction port
Port ISO 11926-1 -
5
/
16
-24
Case pressure port
Port ISO 11926-1 -
7
/
8
-14
∅42.0 max. clearance
dia for fitting
Servo gauge port “M5”
Port ISO 11926-1 -
7
/
16
-20
∅21 max. clearance
dia for fitting
Charge gauge port “M3”
Port ISO 11926-1 -
9
/
16
-18
∅28 max. clearance
dia for fitting
after filtering
Case drain port “L2”
Port ISO 11926-1 - 1
1
/
16
-12
∅48.0 max. clearance
dia for fitting
Charge filtration port “
F
”
∅
20.47
Port ISO 11926-1 -
7
/
8
-14
∅
42.0 max. clearance dia for fitting
to filter
Charge filtration port “
E
”
Port ISO 11926-1 -
7
/
8
-14
∅
42.0 max. clearance dia for fitting
from filter
F F
E
E
Y
231.415 ±1
[9.111 ±0.039]
235.515 ±1
[9.272 ±0.039]
232.515 ±1
[9.154 ±0.039]
77.2 ±1
[3.039 ±0.039]
67 ±1
[2.638 ±0.039]
7 ±1
[0.276±0.039]
53.5 ±1
[2.106 ±0.039]
System B gauge port "MB"
Port ISO 11926-1 -9/16-18
∅28 max clearance dia for fitting
Charge pressure
Construction port
Port ISO 11926-1 -5/16-24
Charge filtration port "F"
Port ISO 11926-1 -7/8-14
∅42 max clearance dia
For fitting to filter
Charge filtration port "E"
Port ISO 11926-1 -7/8-14
∅42 max clearance dia
For fitting from filter
128.4 ±2
[5.055 ±0.079]
206.2 ±2
[8.118 ±0.079]
Case gauge port "M14"
Port ISO 11926-1 -7/16-20
∅21 max clearance dia
For fitting
Please contact Danfoss Power Solutions representative for specific installation drawings.
