1) Pilz relay terminal 4)
Safety relay coil fuse with PILZ relay (see Table 4.24 for part
numbers)
2) RCD or IRM terminal
3) Line power 5)
Electrical fuses, F3 and F4 (3 pieces) (see Table 4.12 to Table 4.16 for
part numbers)
R S T
91 92 93 6) Contactor relay coil (230 VAC). N/C and N/O Aux contacts
(customer supplied)
L1 L2 L3 7) Circuit breaker shunt trip control terminals (230 V AC or 230 V DC)
Figure 4.9 Options Cabinet, Enclosure Types F3 and F4
Electrical Installation
VLT
®
HVAC Drive FC 102
46 Danfoss A/S © 08/2014 All rights reserved. MG11F522
